SOMFY Oximo WT - Wiring; Set-up

41
Copyright © 2005 - 2014 Somfy SAS. All rights reserved. Non contractual images
EN
1. Prior information 41
1. 1. Sphere of application 41
1. 2. Liability 41
2. Installation 42
2. 1. Assembly 42
2. 2. Wiring 43
2. 3. Set-up 43
2. 4. Tips and advice on installation 45
3. Operation and maintenance 48
3. 1. Raising and lowering the roller shutter 48
3. 2. STOP function 48
3. 3. Obstacle detection 48
3. 4. Frost protection 48
4. Tips and advice on operation 49
5. Technical data 49

position reversing switch control point.

- obstacle protection to protect the roller shutter apron when it is being lowered.
- frost protection to protect the roller shutter apron when it is being raised.
CONTENTS
ORIGINAL INSTRUCTIONS
These instructions apply to all Oximo WT drives whatever the torque/speed combination.
1. PRIOR INFORMATION
1. 1. SPHERE OF APPLICATION
The Oximo WT drive is designed to drive all types of roller shutter that meet at least one of

- The driven product is controlled by a press-and-hold control point (wireless or wired) (see
the enclosed Safety instructions document).
- The crush zone is located at a height in excess of 2.50 m from the ground or any permanent
access level.
- The roller shutter is equipped with a safety device that prevents any contact in the crush
zone (a guard that cannot be removed without tools).
- The roller shutter apron can be lifted by 4 cm when an upward force of 150 N is applied to
the end slat positioned 16 cm from its fully extended position.

through the openings.
1. 2. LIABILITY


enclosed Safety instructions document.
The drive must be installed by a home motorisation and automation professional, in
accordance with Somfy's instructions and the applicable regulations in the country of
installation.
Any operation of the drive outside the sphere of application described above is prohibited. Such

to comply with the instructions given herein and in the enclosed Safety instructions document.
             
maintenance conditions for the drive and must pass the operating and maintenance instructions
Safety instructions document.
Any After-Sales Service
operation on the drive requires intervention by a home motorisation and automation professional.

contact or visit www.somfy.com.
Safety Warning!
1
Caution! 
