SOMFY Oximo WT - 3 Operation and Maintenance; Raising and Lowering the Roller Shutter; STOP Function; Obstacle Detection

48
Non contractual images Copyright © 2005 - 2014 Somfy SAS. All rights reserved.
EN
This drive does not require any maintenance operations
3. 1. RAISING AND LOWERING THE ROLLER SHUTTER
1) 
 The roller shutter is raised and automatically stops at
the upper stop.
2) 
 The roller shutter is lowered and automatically stops
at the lower stop.
3. 2. STOP FUNCTION
3. 2. 1. With a non-locking double push-button switch
The driven product is moving.
- 

3. 2. 2. With a locking double push-button switch
1) The driven product is moving upwards.
- 
product stops automatically.
2) The driven product is moving downwards.
- 
driven product stops automatically.
3. 3. OBSTACLE DETECTION


- 
Either the roller shutter stops automatically.
Or it stops and is raised again automatically.
- 

The roller shutter stops automatically.
3. 4. FROST PROTECTION

- 
The roller shutter remains in its initial position.
1) 2)
1)
2)
3. OPERATION AND MAINTENANCE
