3. Description of function and product
3.6 Overview of connection options
Only SOMMER accessories may be used. Observe the
corresponding installation instructions.
Accessories may only be installed and adjusted by
qualified specialists.
Accessories Compatible
LED –
Lock –
Memo ●
USART interface ●
Senso ●
Buzzer ●
Laser ●
Motion –
for OSE/8k2 ●
Wicket door contact –
Output 12 V, 100 mA –
DIP switches 4
Accumulator –
Keypad (Conex connection) –
Relay/Output OC ●
Lumi
+
–
Pulse button ●
Button 2 (partial opening) ●
Warning light 230 V, 40 W ●
Photocell (2- / 4-wire) ●
Output DC 24 V –
Wallstation –
Locking mechanism ●
Pre-end position switch (VES) ●
External command device
2-way / 3-way button
●
STOP button
●
The SOMlink is also available as an accessory.
For more information on accessories, see:
https://downloads.sommer.eu/
3.7 Door types
Roller door*
* With 230 V drive motors with integrated limit switches
up to 1,000 W
