30
9.1 Testing obstacle detection
INFORMATION
After installation of the operator, the
person responsible for installation must
complete an EC Declaration of Conformity
for the door system in accordance with
Machinery Directive 2006/42/EC and
apply the CE mark and a type plate. This
documentation and this installation and
operating manual must be handed over
to the user.
This also applies if the control unit is
retrotted to a manually operated door.
After successful testing of the force settings, the obstacle
detection and the functions, the qualified specialist must
issue the EC Declaration of Conformity and attach the
CE mark and type plate to the door system.
The door must reverse during the door CLOSE movement
if it hits a 40-mm-high obstacle on the ground.
1. Open the door with the operator.
2. Place a 40-mm-high object in the centre of the door.
3. Close the door with the operator.
⇒ If the door hits an obstacle, the operator must
immediately reverse.
⇒ The operator opens the door completely at a pulse
from the transmitter.
9. Final test/handover
9.2 Handover of the door system
The qualified specialist must instruct the user:
• on the operation of the control unit and its dangers
• on the handling of the emergency release (if installed)
• on regular maintenance, testing and care which the
user can carry out, see “Maintenance and care” on
page 34
• on the troubleshooting measures which the user can
carry out, see “Troubleshooting” on page 36
The user must be informed about which work may only be
performed by a qualified specialist:
• Installation of accessories
• Settings
• Regular maintenance, testing and care, except that
described in Chapter “Maintenance and care” on
page 34
• Troubleshooting, except that described in Chapter
“Troubleshooting” on page 36
• Repairs
The following documents for the door system must be
handed over to the user:
• The installation and operating manuals for the
operator and the door
• Inspection book
• EC Declaration of Conformity
• Handover protocol for the control unit/operator
http://som4.me/konform
