7. Electrical connection
7.2 Connection options
1
3-pin terminal block (X1)
Mains connection
230 V
Permissible cable cross-sections: 1.5 mm²–4 mm²
2
2-pin terminal block (X2)
Warning light connection
230 V, max. 40 W, no protective earthing conductor
Optional accessories
Blinks while door is moving
Programmable via SOMlink
DIPswitchcongurationpossible
Permissible cable cross-sections: 1.5 mm²–4 mm²
3
4-pin terminal block (X3)
Motor connection
230 V, 50 Hz, max. 1,000 W
Permissible cable cross-sections: 1.5 mm²–4 mm²
4
4-pin terminal block (X4)
Photocell, 2-wire or 4-wire
2-wire/frame photocell:
DC 24 V
Any polarity
Signal
COM
with status LED, orange
4-wire:
DC 24 V, max.
DC +24 V
GND
Signal
COM
With status LED
Max. installation height: 300 mm
Optional accessories
Door opens fully when safety input trips
Programmable via SOMlink
Permissible cable cross-sections: max. 1.5 mm
5
5-pin terminal block (X5)
Pre-end position switch
Forthedierencesbetween2-wirepre-endpositionswitch
and 4-wire spiral cable, see “Connection overview and DIP
switches” on page 47.
Optical safety contact strip
8k2 safety contact strip
With status LEDs
Optional accessories
Door opens fully when safety input trips
Programmable via SOMlink
DIPswitchcongurationpossible
Permissible cable cross-sections: max. 1.5 mm²
6
6-pin terminal block (X6)
Pulse button
Pulse sequence: OPEN–STOP–CLOSE–STOP
Locking mechanism
With status LEDs
Jumper if locking mechanism is not connected
Stop button
Jumper if button is not connected
Optional accessories
Potential-free
Programmable via SOMlink
Permissible cable cross-sections: max. 1.5 mm²
7
4-pin terminal block (X7)
External command device (3-function pad)
With status LEDs
Jumper between STOP and COM terminals if button
is not connected
Optional accessories
Potential-free
Permissible cable cross-sections: max. 1.5 mm²
