SOMMER RDC Vision+ - Page 17

17
6. Installation
Fig.3
3. Install the control unit in the desired position.
⇒ Minimum height 1.5 m
⇒ Use mounting materials appropriate for the
supporting surface
Fig. 4
4. Close off the two upper screw holes with the sealing
plugs provided.
Fig. 5
5. Hook the cover into the housing as shown or place
it to one side.
