6.6 EXTERNAL INTERRUPT OPERATION (INT0)
INT0 is external interrupt trigger source and builds in edge trigger configuration function. When the external edge
trigger occurs, the external interrupt request flag will be set to “1” no matter the external interrupt control bit enabled or
disable. When external interrupt control bit is enabled and external interrupt edge trigger is occurring, the program
counter will jump to the interrupt vector (ORG 8) and execute interrupt service routine.
The external interrupt builds in wake-up latch function. That means when the system is triggered wake-up from power
down mode, the wake-up source is external interrupt source (P0.0), and the trigger edge direction matches interrupt
edge configuration, the trigger edge will be latched, and the system executes interrupt service routine fist after
wake-up.
0BFH
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
PEDGE
-
-
-
P00G1
P00G0
-
-
-
Read/Write
-
-
-
R/W
R/W
-
-
-
After reset
-
-
-
1
0
-
-
-
Bit[4:3] P00G[1:0]: P0.0 interrupt trigger edge control bits.
00 = reserved.
01 = rising edge.
10 = falling edge.
11 = rising/falling bi-direction (Level change trigger).
 Example: Setup INT0 interrupt request and bi-direction edge trigger.
MOV
A, #18H
B0MOV
PEDGE, A
; Set INT0 interrupt trigger as bi-direction edge.
B0BSET
FP00IEN
; Enable INT0 interrupt service
B0BCLR
FP00IRQ
; Clear INT0 interrupt request flag
B0BSET
FGIE
; Enable GIE
 Example: INT0 interrupt service routine.
ORG
8
; Interrupt vector
JMP
INT_SERVICE
INT_SERVICE:
…
; Push routine to save ACC and PFLAG to buffers.
B0BTS1
FP00IRQ
; Check P00IRQ
JMP
EXIT_INT
; P00IRQ = 0, exit interrupt vector
B0BCLR
FP00IRQ
; Reset P00IRQ
…
; INT0 interrupt service routine
EXIT_INT:
…
; Pop routine to load ACC and PFLAG from buffers.
RETI
; Exit interrupt vector
