Setting the Input Configuration — INPUT
CONFIGURATION Menu
Data pertaining to the input signals are set with the
INPUT CONFIGURATION menu.
When a channel number (1 to 90) is entered with the
numeric keypad, it is then possible to set which input
connector on the rear panel will be assigned to that
channel number, and select the type of signal that will
be connected. The channel numbers from 91 to 99 are
assigned to internal signals.
Assigning Slot and Connector Numbers
Set which input connector on which slot will be
assigned to the current channel. The slots are
numbered from the left, as seen when facing the rear
panel, with the REMOTE connectors slot being
number 1, the input option slots numbers 2 to 5, and
the analog input connectors slot being number 6. The
connectors are numbered 1 to 6 (from the top) for the
slot.
Assigning the Signal Type and Format
The signal type and format which can be assigned to
each channel number vary, depending on what
adaptors are installed in the rear panel.
Assigning serial digital signals
It is possible to assign serial digital signals to the serial
digital input connectors on the BKM-20D/21D/22X
adaptors. However, at least one BKM-21D which
includes the decoder for serial digital signals or BKM-
20D which includes the decoder for serial digital
component signals must be installed.
Assigning analog composite signals
It is possible to assign any composite signal to the
analog signal input connectors of the BKM-20D/21D/
22X, and any of the connectors of the BKM-24N/25P/
26M/27T/28X adaptors. However, at least one of the
following decoder adaptors must be installed:
To assign NTSC signals: BKM-21D/24N/27T
To assign PAL signals: BKM-21D/25P/27T
To assign PAL-M signals: BKM-26M
To assign SECAM signals: BKM-27T
Assigning Y/C signals
It is possible to assign any Y/C signals to the input
connectors of the BKM-24N/25P/26M/27T/28X
adaptors. However, at least one of the following
decoder adaptors must be installed:
To assign NTSC signals: BKM-24N/27T
To assign PAL signals: BKM-25P/27T
To assign PAL-M signals: BKM-26M
Assigning analog component or RGB signals
Analog component and RGB signals can be assigned
to any input connectors except the serial digital signal
input connectors on the BKM-20D/21D/22X.

Sony BVM-14F5U Specifications

General

Screen Size	14 inches
Display Type	CRT
Resolution	Up to 800 TV lines
Aspect Ratio	4:3
Input Connectors	BNC x 2 (Composite, Y/C, RGB), 9-pin D-sub (RGB)
Input	Analog
Color System	NTSC, PAL
Vertical Frequency	50 Hz, 60 Hz
