5
Connector Panel Configuration
The BVM-14F5U/14F5E/14E5U/14E5E comes
standard with connectors for one channel of Y/R–Y/B–
Y or RGB. By adding optional decoder adaptors and/
or input expansion adaptors, the input/output connector
panel can be assembled in a wide variety of
configurations.
The signals that each of the adaptors’ connectors
supports are given in the table below. The type of
signal to be applied to each input/output connector is
set with the INPUT CONFIGURATION menu.
When the type of input signal determines, each
connector of the installed adaptors is connected with
the decoder for the corresponding signal over an
internal bus. Therefore, if one decoder adaptor for a
signal is installed, the signal input from any connector
of the installed adaptors can be decoded.
Notes
• Only one BKM-22X board can be installed in the
monitor together with either the BKM-20D or the
BKM-21D.
• The BKM-20D, BKM-21D, and BKM-22X can not
provide proper active-through outputs if a signal
whose format is not selected in the INPUT
CONFIGURATION menu is input. (If AUTO is
selected, input a signal which has the same format
with the signal monitored last.)
For information about the INPUT CONFIGURATION
menu, see “Setting the Input Configuration —INPUT
CONFIGURATION Menu” on page 32.
Y/C
PAL
BKM-21D
SDI Multi
Decoder
Adaptor
Adaptor name
BKM-24N
NTSC
Decoder
Adaptor
BKM-25P
PAL
Decoder
Adaptor
BKM-26M
PAL-M
Decoder
Adaptor
BKM-27T
Tri-
Standard
Decoder
Adaptor
BKM-22X
SDI Input
Expansion
Adaptor
BKM-28X
Analog
Input
Expansion
Adaptor
Composite
NTSC
Composite
PAL
Composite
NTSC
Composite
PAL
Composite
PAL-M
Component
525/625
Composite
SECAM
Y/R–Y/B–Y
525/625
RGB 525/
625
Y/C
NTSC
Serial
digital
input
Analog
input
O
O
O
O
O
®
®
O
O
O
®
®
®
O
O
O
®
O
®
®
O
O
O
®
®
O
®
O
O
O
O
®
O
O
O
O
O
®
®
®
®
®
®
®
O
O
®
®
®
®
O
O
®
®
®
®®
®
BKM-20D
SDI 4:2:2
Decoder
Adaptor
O
®
®
®
®
O
O
Number of analog
input
Number of digital
inputs
Y/C
PAL-M
336
6
6636
33–
–
––3
–
O: Independent input possible
®® ®
®
O
®
®
®: Input possible when used with decoder adaptor
