Sony BVM-14F5U - Connection Cable Specifications for Color Temperature Probes

29
282 ADJUST (STD/COL1/COL2/xxCH) (1/2): Adjust the gain with the proper
knob.
GAIN R:xxxx G:xxxx B:xxxx
282 ADJUST (STD/COL1/COL2/xxCH) (2/2): Adjust the bias with the proper
knob.
BIAS R:xxxx G:xxxx B:xxxx
Connection Cable Specifications for Color Temperature Probes
Signal Pin Number
Signal Pin Number
Special cables are required to connect color
temperature probes other than the Sony BKM-14L to
the monitor.
The following diagrams show specifications and pin
assignments for the required cables.
Connection cable for Minolta CA-100 probe
D-sub 25-pin connector Mini DIN 8-pin connector
(male) (male)
N.C.
TXD
RXD
RTS
CTS
N.C.
GND
N.C.
1
2
3
4
5
6
7
8-25
H SYNC
V SYNC
RTS
GND
N.C.
TXD
+5V
RXD
1
2
3
4
5
6
7
8
1
2
3
6
8
5
113
14 25
