Specifications
General
System 525 lines, 60 fields per second
interlaced
625 lines, 50 fields per second
interlaced
CRT Super fine pitch Trinitron
Aperture grille pitch:
0.25 mm (BVM-14F5U/14F5E)
or 0.22 mm (BVM-14E5U/
14E5E), 90-degree deflection,
29.4 mm diameter in-line gun.
Effective picture size:
268 × 201 mm (10
5
/8 × 8 inches)
(w/h)
332 mm (13
1
/8 inches) (diagonal
size)
CRT protection: EHT (extremely
high tension) protectiontype
Warm-up time: approx. 30 minutes
Anode voltage: 25 kV with no
beam current
Nominal chromaticity coordinates:
SMPTE phosphor (BVM-14F5U)
EBU phosphor (BVM-14F5E)
Power requirements
100 to 240 V AC, 10%, 50/60 Hz
Power consumption
110 W
Dimensions 482 × 280 × 530 mm
(19 × 11
1
/8 × 20
7
/8 inches)
(w/h/d)
Mass Approx. 25 kg (55 lb 1 oz)
Input/output Connectors
Video input BNC type, 3 (with three loop-
through outputs)
R/G/B: 1 Vp-p ±6 dB, positive,
high impedance
Y: 1 Vp-p ±6 dB, positive, high
impedance
R–Y/B–Y: 0.7 Vp-p ±6 dB,
positive, high impedance
Sync input BNC type, 1 (with loop-through
output)
Composite sync: 0.3 to 8 Vp-p,
negative, high impedance
Return loss More than 46 dB (7 MHz, with 75-
ohm termination)
Remote control OPTION
Mini-DIN 8-pin, 1
CONTROL UNIT
D-sub 9-pin, 1
REMOTE 1
D-sub 9-pin, 1 (with loop-
through output), RS-485 serial
interface
REMOTE 2
D-sub 9-pin, 1 (with loop-
through output)
ISR
D-sub 9-pin, 1
Video Signal
Differential gain Less than 2% (for luminance from
0 to 100 cd/m
2
)
Differential phase Less than 2° (for luminance from 0
to 100 cd/m
2
)
Frequency response
100 Hz to 10 MHz, ±1 dB
DC restoration Back porch type
Black level: fluctuation less than
1% for 10 to 90% APL input
signal variation.
xy
R 0.630 0.340
G 0.310 0.595
B 0.155 0.070
xy
R 0.640 0.330
G 0.290 0.600
B 0.150 0.060
