61
Synchronization
AFC time Constant 0.5 ms (fast mode)
2 ms (normal mode)
Line pull range/line hold range
Greater than ±500 Hz (with 0.5 ms
AFC time constant)
Vertical blanking time
Normal: less than 1 ms.
Underscan: less than 0.8 ms
Horizontal blanking time
Less than 10 µs
Picture Performance
Normal scan 5% overscan of CRT effective
screen area (adjustable range
greater than ±15%)
Underscan 3% underscan of CRT effective
screen area (adjustable range
greater than ±15%)
Linearity Within a central area bounded by a
circle with a diameter equal to the
picture height, less than 0.5% of
the picture height, and outside the
same area, about 1% of the
picture height
Color temperature
D65, D93 (adjustable to other color
temperatures)
Convergence error
Within a central area bounded by a
circle with a diameter equal to the
picture height: less than 0.3 mm
Outer area of the above-mentioned
circle: less than 0.6 mm
Standard luminescence
100 cd/m
2
(at standard 1 Vp-p
100% white signal)
Raster size stability
Less than 1% of picture height (at
100 cd/m
2
peak luminescence, 10
to 90% APL)
Scan delay Horizontal: Approx.
1
/
4
line
Vertical: Approx.
1
/
2
field
Resolution BVM-14F5U/14F5E:
800 TV lines (at screen center,
100 cd/m
2
luminescence)
BVM-14E5U/14E5E:
900 TV lines (at screen center,
100 cd/m
2
luminescence)
Environmental Conditions
Operating temperature
0°C to 40°C (32°C to 104°F)
Optimum operating temperature
20°C to 30°C (68°F to 86°F)
Operating humidity
0% to 90% (no condensation)
Accessories Supplied
AC power cord (1)
Cord stopper (1)
Tally plate (1)
Operation manual (1)
Fuse (2)
Design and specifications are subject to change
without notice.
