342 1-8 PIN (2/2): Assign a function to the selected pin.
BLUE ONLY: Set the blue signal pictures display (monochrome) on or off.
R OFF: Set cutting red beams enabled or disabled.
G OFF: Set cutting green beams enabled or disabled.
B OFF: Set cutting blue beams enabled or disabled.
VITC ON: Set the VITC display on or off.
SAFE AREA ON: Set the safe area display on or off.
CAPTION VISION: Set the caption vision on or off.
TALLY ON: Set tally signals on or off.
DEGAUSS ON: Set degaussing on or off.
POWER OFF: Set the monitor power on or off.
For information about pin connections, see the description of the REMOTE 2 connector in “Location
and Function of Parts” on page12.
343 REMOTE 1 CONFIG: Set the monitor address, group address and remote mode of
the monitor.
MONITOR ADDRESS: Enter a number.
GROUP ADDRESS: Enter a number.
REMOTE MODE: Select the remote mode. ÷ 344
344 REMOTE MODE: Select a remote mode according to the type of monitors
connected through the REMOTE1 connector.
When only Sony BVM-xxE/F series monitors are connected, set REMOTE MODE to 0.
When a Sony BVM-xx11/16 series monitor or a Sony PVM monitor (with BKM-103
Serial Remote Interface Kit installed) is connected, set REMOTE MODE to 1 and enter a
number over 64 as the MONITOR ADDRESS for each connected Sony BVM-xxE/F series
monitor.
Assigning the Remote Control Functions — REMOTE Menu
