49
700 ALIGNMENT menu (1/4): Adjust each item with the UP and DOWN buttons or PHASE knob.
ROTATION: Compensates for the screen rotation which occurs when the monitor is installed facing
north or south.
H PHASE: Adjust the horizontal picture position.
V CENTER: Adjust the vertical picture position.
H SIZE: Adjust the width of the picture.
V SIZE: Adjust the height of the picture.
V LIN AMP: Adjust the vertical linearity of the picture.
V LIN BAL: Adjust the balance of the vertical linearity of the picture.
VITS BLK: Adjust vertical blanking so that VITS signals are not visible in the upper part of the
screen.
700 ALIGNMENT menu (2/4): Adjust each item with the UP and DOWN buttons or PHASE knob.
H PIN: Correct side pincushion distortion.
H PIN BAL: Correct the balance of side pincushion distortion.
H CORNER PIN: Correct pincushion distortion at the corner of the picture.
H CENTER PIN: Correct center bow distortion.
H MID PIN: Correct pincushion distortion at the middle of the picture.
H KEY: Correct trapezoid distortion.
H KEY BAL: Correct the balance of trapezoid distortion.
H LIN: Correct horizontal linearity.
H LIN BAL: Correct the balance of horizontal linearity.Monitor Memory Card Data Operations
700 ALIGNMENT menu (3/4): Adjust each item with the UP and DOWN buttons or PHASE knob.
V STATIC CONV: Adjust vertical static convergence.
V CONV TOP: Adjust vertical convergence at the top of the screen.
V CONV BOT: Adjust vertical convergence at the bottom of the screen.
H STATIC CONV: Adjust horizontal static convergence.
H CONV C T: Adjust horizontal convergence at the top of the screen.
H CONV C B: Adjust horizontal convergence at the bottom of the screen.
H CV C M T: Adjust horizontal convergence at the middle between the top and the center of the
screen.
H CV C M B: Adjust horizontal convergence at the middle between the bottom and the center of the
screen.
