Display Function Menu
Chapter 3 Menu
Gamut Error Display Sets the gamut error display.
You can select when the BKM-220D, BKM-243HS or BKM-244CC is installed.
Notes
• The gamut error display function is effective when D1 or HD-SDI (except 2048 × 1080 RGB
and XYZ) signal is input.
The gamut error display function does not work in the following cases:
- When the input signal has no sync signal
- When the internal signal is displayed
- When H Delay/V Delay is set to On
- When Side by Side is set to On
- When Wipe is set to On
- When Butterfly is set to On
- When Blending is set to On
- When Black Detail Mode is set to On
• In under scan mode, each one line of the upper and lower lines of the video signal is also
detected for gamut error display.
• In over scan mode, 5% mask portion is also detected for gamut error display. However, the
zebra pattern is not displayed on 5% mask portion.
Gamut Error Display Sets whether or not to display the gamut error ([Off] or On).
Notification Sets the error detection mode.
[LED]: The STATUS lamp lights when the error is detected.
LED&OSD: The STATUS lamp lights and the message of the error notification appears
on the screen when the error is detected.
Notification Reset Sets the method to reset the error detection mode.
[Auto]: Resets automatically after detecting the error.
Manual: Resets manually. To reset the error detection, press the button to which the
Error Notify Clear function is assigned or set the pin of the PARALLEL REMOTE
connector to which the Error Notify Clear function is assigned to On.
For assignment to the function button, see page 80 and for assignment to the PARALLEL
REMOTE connector, see page 70.
Input Detection Sets the error detection of the input signal.
Detection Sets whether or not to detect the error of the input signal (Off or [On]).
Pixel Threshold Sets the pixel number of the gamut error in the frame to notify the gamut error detection.
When the pixel number of the error is over the set pixel number, the detection is notified.
Set to 00000 to 65535. [00000]
Signal Level Sets the upper and lower lines of every signal to detect the gamut error.
D1/HD-SDI YPbPr 10bit Upper Limit (upper limit)
Y: 0000 to 1023 [0983]
Pb: 0000 to 1023 [1004]
Pr: 0000 to 1023 [1004]
Lower Limit (lower limit)
Y: 0000 to 1023 [0020]
Pb: 0000 to 1023 [0019]
Pr: 0000 to 1023 [0019]
HD-SDI RGB 10bit When two BKM-243HS or BKM-244CC are installed in the OPTION 1 and 2 or OPTION 3
and 4 option slots, you can select this item.
Upper Limit (upper limit)
G: 0000 to 1023 [0983]
B: 0000 to 1023 [0983]
R: 0000 to 1023 [0983]
Lower Limit (lower limit)
G: 0000 to 1023 [0020]
B: 0000 to 1023 [0020]
R: 0000 to 1023 [0020]
Menu Function and operation ([ ]: factory setting)
