Display Function Menu
Chapter 3 Menu
Gamut Error Display
HD-SDI YPbPr 12bit When two BKM-243HS or BKM-244CC are installed in the OPTION 1 and 2 or OPTION 3
and 4 option slots, you can select this item.
Upper Limit (upper limit)
Y: 0000 to 4095 [3935]
Pb: 0000 to 4095 [4019]
Pr: 0000 to 4095 [4019]
Lower Limit (lower limit)
Y: 0000 to 4095 [0080]
Pb: 0000 to 4095 [0077]
Pr: 0000 to 4095 [0077]
HD-SDI RGB 12bit When two BKM-243HS or BKM-244CC are installed in the OPTION 1 and 2 or OPTION 3
and 4 option slots, you can select this item.
Upper Limit (upper limit)
G: 0000 to 4095 [3935]
B: 0000 to 4095 [3935]
R: 0000 to 4095 [3935]
Lower Limit (lower limit)
G: 0000 to 4095 [0080]
B: 0000 to 4095 [0080]
R: 0000 to 4095 [0080]
Post-Process Detection Sets the error detection setting for the signal after YPbPr is converted to RGB.
Detection Sets whether or not to detect the error of the input signal ([Off] or On).
Pixel Threshold Sets the pixel number of the gamut error in the frame to notify the gamut error detection.
When the pixel number of the error is over the set pixel number, the detection is notified.
Set to 00000 to 65535. [00000]
Signal Level Sets the upper and lower lines of the signal level.
The signal level to be set is black level 256 and white level 3760 in 12bit conversion value.
Upper Limit: 0000 to 4095 [3761]
Lower Limit: 0000 to 4095 [0255]
Zebra Pattern Sets the zebra pattern displayed by the gamut error detection.
Note
When the setting for the zebra pattern is changed, Zebra Pattern of Black Detail Setting is
also set to the same setting value.
Line Sets the direction of the pattern.
[Diagonal Type1]: Right descending
Diagonal Type2: Left descending
Modulation Sets the amplitude of the pattern display.
Set to 1 to 50. [16]
Black Detail Setting Sets the black detail mode.
Clip Indicator Sets whether or not to display a zebra pattern in the clipped portions with high color gradation
on the black detail mode display (Off
or [On]).
Zebra Pattern Sets the zebra pattern displayed in the clipped portions.
Note
When the setting for the zebra pattern is changed, Zebra Pattern of Gamut Error Display is
also set to the same setting value.
Line Sets the direction of the pattern.
[Diagonal Type1]: Right descending
Diagonal Type2: Left descending
Modulation Sets the amplitude of the pattern display.
Set to 1 to 50. [16]
Capture Captures the still picture for the standard of the color evaluation.
Load Loads the captured picture from the “Memory Stick”.
When the item is selected, you can select the file name to be loaded.
