Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-676-530-11 POWER BOARD
*************
1-533-233-31 HOLDER, FUSE (E4)
< CAPACITOR >
C908 1-126-964-11 ELECT 10uF 20% 50V
< AC INLET >
0CNJ901 1-526-818-11 INLET, AC 2P (- AC IN) (E92,MX)
0CNJ901 1-526-838-11 INLET, AC 2P (- AC IN) (EXCEPT US,CND,
E92,MX)
0CNJ901 1-540-009-11 INLET, AC 2P (- AC IN) (US,CND)
< CONNECTOR >
* CNP901 1-580-155-11 PIN, CONNECTOR (PC BOARD) 3P
* CNP902 1-580-165-21 PIN, CONNECTOR (PC BOARD) 4P
* CNP905 1-564-752-11 PIN, CONNECTOR (WITH LOCK) 3P (E4,JE)
*************************************************************
* A-3322-448-A PRE BOARD, COMPLETE
********************
< CAPACITOR >
C101 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C102 1-104-664-11 ELECT 47uF 20% 10V
C103 1-162-587-11 CERAMIC CHIP 0.039uF 10% 25V
C104 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C105 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C106 1-126-960-11 ELECT 1uF 20% 50V
C201 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C202 1-104-664-11 ELECT 47uF 20% 10V
C203 1-162-587-11 CERAMIC CHIP 0.039uF 10% 25V
C204 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C205 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C206 1-126-960-11 ELECT 1uF 20% 50V
C301 1-104-665-11 ELECT 100uF 20% 10V
C302 1-104-665-11 ELECT 100uF 20% 10V
C303 1-104-665-11 ELECT 100uF 20% 10V
C304 1-104-664-11 ELECT 47uF 20% 10V
C305 1-137-431-11 MYLAR 560PF 5% 50V
C306 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C307 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
< CONNECTOR >
CNP301 1-568-830-11 CONNECTOR, FFC 11P
< IC >
IC301 8-759-264-71 IC TA2068N
< TRANSISTOR >
Q301 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
< RESISTOR >
R101 1-216-077-11 RES-CHIP 15K 5% 1/10W
R102 1-216-023-00 METAL CHIP 82 5% 1/10W
R103 1-216-097-11 RES-CHIP 100K 5% 1/10W
R104 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R105 1-216-077-11 RES-CHIP 15K 5% 1/10W
R106 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R110 1-216-025-11 RES-CHIP 100 5% 1/10W
R111 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R201 1-216-077-11 RES-CHIP 15K 5% 1/10W
R202 1-216-023-00 METAL CHIP 82 5% 1/10W
R203 1-216-097-11 RES-CHIP 100K 5% 1/10W
R204 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R205 1-216-077-11 RES-CHIP 15K 5% 1/10W
R206 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R210 1-216-174-00 RES-CHIP 100 5% 1/8W
R211 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R301 1-216-121-11 RES-CHIP 1M 5% 1/10W
R302 1-216-214-00 RES-CHIP 4.7K 5% 1/8W
R303 1-216-214-00 RES-CHIP 4.7K 5% 1/8W
R304 1-216-198-11 RES-CHIP 1K 5% 1/8W
R305 1-216-180-00 RES-CHIP 180 5% 1/8W
R306 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R307 1-216-150-11 RES-CHIP 10 5% 1/8W
R308 1-216-081-00 METAL CHIP 22K 5% 1/10W
R309 1-216-166-00 RES-CHIP 47 5% 1/8W
< SWITCH >
S301 1-762-565-11 SWITCH, SLIDE (REC/PB)
< TRANSFORMER >
T301 1-416-041-11 TRANSFORMER, BIAS OSCILLATION
*************************************************************
* 1-676-629-11 SECONDARY BOARD
*****************
1-533-233-31 HOLDER, FUSE (EXCEPT US)
< CAPACITOR >
C901 1-101-005-00 CERAMIC 22000PF 50V
C902 1-101-005-00 CERAMIC 22000PF 50V
C903 1-101-005-00 CERAMIC 22000PF 50V
C904 1-101-005-00 CERAMIC 22000PF 50V
< DIODE >
D901 8-719-063-79 DIODE 1N4002B
D902 8-719-063-79 DIODE 1N4002B
D903 8-719-063-79 DIODE 1N4002B
D904 8-719-063-79 DIODE 1N4002B
*************************************************************
PREPOWER
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
SECONDARY
