Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
TUNER
* A-3322-456-A TUNER BOARD, COMPLETE (US,CND,E92,MX)
* A-3322-558-A TUNER BOARD, COMPLETE (SP,AR)
* A-3322-621-A TUNER BOARD, COMPLETE (AUS)
* A-3322-694-A TUNER BOARD, COMPLETE (E4,JE)
***********************
< CAPACITOR >
C4 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C8 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C9 1-163-098-00 CERAMIC CHIP 16PF 5% 50V
C10 1-126-960-11 ELECT 1uF 20% 50V
C11 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C12 1-126-963-11 ELECT 4.7uF 20% 50V
C14 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
(E4,SP,AR,AUS,JE)
C14 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
(US,CND,E92,MX)
C15 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
(E4,SP,AR,AUS,JE)
C15 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
(US,CND,E92,MX)
C16 1-126-960-11 ELECT 1uF 20% 50V
C17 1-126-960-11 ELECT 1uF 20% 50V
C18 1-126-934-11 ELECT 220uF 20% 10V
C19 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C20 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C21 1-126-960-11 ELECT 1uF 20% 50V
C22 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C23 1-126-960-11 ELECT 1uF 20% 50V
C24 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C26 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C27 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C28 1-104-665-11 ELECT 100uF 20% 10V
C30 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C31 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C32 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C33 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C34 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C35 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C41 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C42 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C44 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C47 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C51 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C52 1-163-098-00 CERAMIC CHIP 16PF 5% 50V
C53 1-136-171-00 MYLAR 0.33uF 5% 50V
C54 1-126-934-11 ELECT 220uF 20% 10V
C55 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C56 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C57 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C58 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C59 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C60 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C61 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C62 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C63 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C64 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C66 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C68 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C77 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C80 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C93 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C95 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
< FILTER >
CF2 1-760-738-61 FILTER, CERAMIC
CF4 1-781-749-11 FILTER, AM CERAMIC
< CONNECTOR >
* CNP1 1-785-663-11 PIN, CONNECTOR (PC BOARD) 11P
< TRIMMER >
CT1 1-141-227-00 CAP, TRIMMER 20PF
CT3 1-141-304-21 CAP, TRIMMER 10PF
< DIODE >
D1 8-719-078-48 DIODE KV1471ETR1-3
D2 8-719-078-48 DIODE KV1471ETR1-3
D3 8-719-050-69 DIODE KV1520NT
D10 8-719-988-61 DIODE 1SS355TE-17
D11 8-719-988-61 DIODE 1SS355TE-17
< JUMPER RESISTOR >
FB1 1-216-295-00 SHORT 0
< IC >
IC1 8-759-662-67 IC TA2149N
IC2 8-759-483-40 IC LC72137M-TLM
< JUMPER RESISTOR >
JC8 1-216-295-00 SHORT 0
JC9 1-216-295-00 SHORT 0
JC10 1-216-295-00 SHORT 0
JC14 1-216-295-00 SHORT 0
JC15 1-216-295-00 SHORT 0
JC16 1-216-295-00 SHORT 0
JC18 1-216-295-00 SHORT 0
JC19 1-216-295-00 SHORT 0
JC20 1-216-295-00 SHORT 0
JC21 1-216-295-00 SHORT 0
JC23 1-216-295-00 SHORT 0
JC24 1-216-295-00 SHORT 0
JC25 1-216-295-00 SHORT 0 (E4,SP,AR,AUS,JE)
JC27 1-216-295-00 SHORT 0
JC28 1-216-295-00 SHORT 0
JC29 1-216-295-00 SHORT 0
