– 65 –
Ref. No. Part No. Description Remark
TUNER
Ref. No. Part No. Description Remark
JC30 1-216-295-00 SHORT 0
JC31 1-216-295-00 SHORT 0
JC33 1-216-295-00 SHORT 0
JC38 1-216-295-00 SHORT 0
JC39 1-216-295-00 SHORT 0
JC40 1-216-295-00 SHORT 0
JC41 1-216-295-00 SHORT 0
JC42 1-216-295-00 SHORT 0
JC43 1-216-295-00 SHORT 0
JC44 1-216-295-00 SHORT 0
< COIL >
L1 1-416-533-11 COIL, AIR-CORE
L2 1-416-509-11 COIL, AIR-CORE
L3 1-754-117-11 ANTENNA, FERRITE-ROD (AM)
L4 1-411-234-21 COIL, AM OSC
L11 1-414-142-11 INDUCTOR 1uH (US,CND,E92,MX)
L21 1-410-509-11 INDUCTOR 10uH
< RESISTOR >
R1 1-216-037-00 METAL CHIP 330 5% 1/10W
R2 1-216-033-00 METAL CHIP 220 5% 1/10W
R3 1-216-073-00 METAL CHIP 10K 5% 1/10W
R4 1-216-073-00 METAL CHIP 10K 5% 1/10W
R5 1-216-295-00 SHORT 0
R10 1-216-166-00 RES-CHIP 47 5% 1/8W
R11 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R13 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
R24 1-216-033-00 METAL CHIP 220 5% 1/10W
R25 1-216-001-00 METAL CHIP 10 5% 1/10W
R30 1-216-077-11 RES-CHIP 15K 5% 1/10W
R31 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R32 1-216-097-11 RES-CHIP 100K 5% 1/10W
R40 1-216-105-11 RES-CHIP 220K 5% 1/10W
R41 1-216-073-00 METAL CHIP 10K 5% 1/10W
R50 1-216-198-11 RES-CHIP 1K 5% 1/8W
R51 1-216-073-00 METAL CHIP 10K 5% 1/10W
R53 1-216-075-00 METAL CHIP 12K 5% 1/10W
R54 1-216-043-11 RES-CHIP 560 5% 1/10W
R56 1-216-041-00 METAL CHIP 470 5% 1/10W
R58 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
R59 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
R60 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
R61 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
R63 1-216-222-00 RES-CHIP 10K 5% 1/8W
R65 1-216-073-00 METAL CHIP 10K 5% 1/10W
R91 1-216-198-11 RES-CHIP 1K 5% 1/8W
R92 1-216-198-11 RES-CHIP 1K 5% 1/8W
R93 1-216-295-00 SHORT 0
R94 1-216-049-11 RES-CHIP 1K 5% 1/10W
< TRANSFORMER >
T1 1-435-333-11 TRANSFORMER, IF
T2 1-419-465-11 COIL (DET)
< VIBRATOR >
X1 1-760-130-11 VIBRATOR, CRYSTAL (75kHz) (E4,SP,AR,JE)
X1 1-781-592-11 VIBRATOR, CRYSTAL (75kHz)
(US,CND,E92,MX,AUS)
*************************************************************
* 1-677-512-11 VOL SEL BOARD (E4)
**************
< SWITCH >
0S901 1-552-921-00 SWITCH, POWER (VOLTAGE SELECTOR)
*************************************************************
MISCELLANEOUS
***************
8 1-792-206-11 CABLE, FLEXIBLE FLAT (6 CORE) (S22)
8 1-792-207-11 CABLE, FLEXIBLE FLAT (8 CORE) (S32)
102 1-792-204-11 CABLE, FLEXIBLE FLAT (11 CORE)
111 1-792-205-11 CABLE, FLEXIBLE FLAT (21 CORE)
118 1-452-899-11 MAGNET
126 1-792-209-11 WIRE, PARALLEL (16 CORE)
128 1-792-208-11 WIRE, PARALLEL (17 CORE)
0251 8-848-483-05 OPTICAL PICK-UP KSS-213C
254 X-2626-202-1 CHASSIS ASSY (MB), MOTOR (SPINDLE)
(INCLUDING M701)
ANT1 1-501-883-21 ANTENNA, TELESCOPIC (FM)
0F901 1-532-467-51 FUSE (0.315A/250V) (E4,JE)
0F902 1-532-388-51 FUSE (2A/250V) (E4,JE)
0F902 1-532-464-51 FUSE (2.5A/250V) (SP,AR,AUS)
0F902 1-576-107-11 FUSE (3.15A/250V) (CND)
HE301 1-543-876-11 HEAD (ERASE)
HRP301 1-500-454-11 HEAD, MAGNETIC (RECORD/PLAYBACK)
M301 A-3320-446-A MOTOR ASSY (CAPSTAN/REEL)
M702 X-2625-769-1 GEAR ASSY (MB), MOTOR (SLED)
S304 1-692-302-11 SWITCH, LEAF (TAPE PLAY)
S501 1-692-960-11 SWITCH, PUSH (1 KEY) (CD DOOR
OPEN/CLOSE)
SP301 1-529-215-11 SPEAKER (10cm) (L-CH) (US,CND)
SP301 1-529-340-11 SPEAKER (10cm) (L-CH) (EXCEPT US,CND)
SP302 1-529-215-11 SPEAKER (10cm) (R-CH) (US,CND)
SP302 1-529-340-11 SPEAKER (10cm) (R-CH) (EXCEPT US,CND)
0T901 1-433-576-11 TRANSFORMER, POWER (US,CND,E92,MX)
0T901 1-433-578-11 TRANSFORMER, POWER (SP,AR,AUS)
0T901 1-435-508-11 TRANSFORMER, POWER (E4,JE)
*************************************************************
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
