Preparations 2-29
Chapter 2 Preparations
Video settings page 2/2
Item
Setting
PROCESS
CONTROL
PANEL
Y/C DLY
800
PRESET
SYNC PH
80
SC PH
200
SG
OFF
VID SG
CB75
a)
AUD SG
SILNC
PROCESS
CONTROL
Select SETUP when you want to adjust the following items with the setup
menu, and PANEL when you want to adjust them with the submenus and the
lower control panel.
• Output video level
• Chroma output level
• Setup level (525/60 mode)
• Black level (625/50 mode)
• Chroma phase
• Y/C delay
• Sync/subcarrier phase
Y/C
DELAY
When the “PROCESS CONTROL” is set to PANEL, set the Y/C delay value.
PRESET: Fixed at factory default level.
VAR: Adjustable as desired.
To adjust
Press operation button F4 to indicate the VAR, press F4 again to highlight the
value, and then press the MARK/UP or LIST/DOWN button to change the value.
SYNC PH
When the “PROCESS CONTROL” is set to PANEL, adjust the sync phase by
pressing the MARK/UP or LIST/DOWN button.
SC PH
When the “PROCESS CONTROL” is set to PANEL, adjust the subcarrier
phase by pressing the MARK/UP or LIST/DOWN button. The SC-H value is
constant.
SG Select the output of the internal audio or video signal generator for the source
signal.
OFF : Neither of the output of the internal audio nor video signal generator
AUDIO: The output of the internal audio signal generator
VIDEO : The output of the internal video signal generator
BOTH: Both of the output of the internal audio and video signal generators
AUD SG
Select the operation of the internal audio test signal generator.
SILNC : Silent signal.
1kHz : At 1 kHz, –20 dB FS sine wave is supplied to all audio input channels.
ID: Signal for recognizing each channel.
a) For 525 mode, CB100 for 625 mode.
