Preparations 2-25
Chapter 2 Preparations
Item Setting
LINE OUT Select channels 1/2 or 3/4 as the line out channels.
MONITOR Select FIX for an output level determined according to the setting (either
PRESET or VARIABLE) of the PB AUDIO PRESET/VARIABLE switch of
the control panel, or VAR for an output level linked also to the LEVEL knob
on the front control section.
MONITOR Select monitor output L and R signals (up to four).
To select
Select channel for L using operation button F3 and channel for R using
operation button F4, and press the UP or DOWN button to add the asterisk
to the position of the desired channel.
L Select from channels 1 to 4.
R Select from channels 1 to 4.
a) Dolby noise reduction manufactured under
license from Dolby Laboratories Licensing
Corporation.
Audio settings pages 2-1 to 4-3
Make settings in the same way as
pages 1-1 to 1-3.
EMPH Set to ON when you want to add emphasis.
DOLBY When playing back oxide tapes recorded in Betacam format, set to ON or
OFF to match the Dolby
a)
setting at the time of recording.
“DOLBY” and the double-D symbol a are
trademarks of Dolby Laboratories
Licensing Corporation.
2-7-2 Making Settings in the Audio Settings Subpages
Use the audio settings subpages to
make mix and swap input and output
settings for channel 1 and channel 2.
To display the audio settings
subpages
1 Press operation button F1 to
highlight the audio settings item
in the home page.
2 If the item displayed is not “MIX/
SWP”, press the UP button until
“MIX/SWP” appears.
3 Press the PAGE button.
An audio settings subpage (input
mixing page) appears as shown
below (next page).
To Next Page
