HCD-BC150/BC250
Pin No. Pin Name I/O Description
189 DVSS — Terminal Ground
190 VFO13 O Not used (open)
191 IDGATE O Not used (open)
192 DVDD3 — Power Supply (+3.3V)
193 UPGATE O Not used (open)
194 WOBSI O Not used (open)
195 SDATA I DATA RF signal input from RF AMP (IC102)
196 SDEN O SDEN signal output to RF AMP (IC102)
197 SLCK O CLK RF signal output to RF AMP (IC102)
198 BDO I BOO signal input from RF AMP (IC102)
199 ADCVSS — Terminal Ground
200 ADIN I ADIN signal input from RF AMP (IC102)
201 RFSUBI I Not used (open)
202 TEZISLV I Tracking error zero crossing low pass input
203 TEI I TE signal input from RF AMP (IC102)
204 CSO I CSO signal input from RF AMP (IC102)
205 FEI I FE signal input from RF AMP (IC102)
206 RFLEVEL I PI signal input from RF AMP (IC102)
207 RFAPDC I RFRP signal input from RF AMP (IC102)
208 RFAPAC I RFRP signal input from RF AMP (IC102)
209 HRFZC I RFZC signal input from RF AMP (IC102)
210 PWMVREF I VIP4 signal input from RF AMP (IC102)
211 PWM2VREF I V2P8 signal input from RF AMP (IC102)
212 ADCVDD3 — Power Supply (+3.3V)
213 RFOTSLVP O Not used (open)
214 RFOTSLVN O Not used (open)
215 RFIN I RFIN signal input from RF AMP (IC102)
216 RFIP I RFIP signal input from RF AMP (IC102)
