Sony HCD-BC150 - PANEL

84
HCD-BC150/BC250
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< VIBRATOR >
X201 1-781-867-21 VIBRATOR, CRYSTAL (27MHz)
************************************************************
ENCODER BOARD
**************
************************************************************
FL BOARD
********
< CAPACITOR >
C839 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C840 1-126-795-11 ELECT 10uF 20% 50V
C841 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C842 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C843 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C845 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C846 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C847 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C848 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C849 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C850 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C851 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C852 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C853 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C854 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C855 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C856 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C857 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C858 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CN803 1-568-828-11 CONNECTOR, FFC 9P
< FLUORESCENT INDICATOR >
FL801 1-518-968-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC803 8-759-643-83 IC uPD16315GB-3BS
< TRANSISTOR >
Q814 8-729-034-51 TRANSISTOR KTC3875
Q815 8-729-034-51 TRANSISTOR KTC3875
< RESISTOR >
R853 1-216-809-11 METAL CHIP 100 5% 1/10W
R854 1-216-809-11 METAL CHIP 100 5% 1/10W
R858 1-216-809-11 METAL CHIP 100 5% 1/10W
R860 1-216-844-11 METAL CHIP 82K 5% 1/10W
R862 1-216-845-11 METAL CHIP 100K 5% 1/10W
R863 1-216-845-11 METAL CHIP 100K 5% 1/10W
R868 1-216-833-11 METAL CHIP 10K 5% 1/10W
R872 1-216-833-11 METAL CHIP 10K 5% 1/10W
R874 1-216-845-11 METAL CHIP 100K 5% 1/10W
R875 1-216-845-11 METAL CHIP 100K 5% 1/10W
************************************************************
1-861-263-11 H/P BOARD
*********
< CAPACITOR >
C800 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C801 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C802 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C803 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C804 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C806 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
< CONNECTOR >
CN804 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE) 5P
< DIODE >
D800 8-719-988-61 DIODE 1SS355TE-17
D801 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB800 1-500-284-21 INDUCTOR, FERRITE BEAD
FB801 1-216-295-91 SHORT CHIP 0
FB802 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB803 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB805 1-469-144-21 FERRITE, EMI (SMD) (2012)
< JACK >
J800 1-566-891-21 JACK (PHONES)
< COIL >
L800 1-410-387-11 INDUCTOR 33uH
L801 1-410-387-11 INDUCTOR 33uH
L802 1-469-144-21 FERRITE, EMI (SMD) (2012)
L803 1-469-144-21 FERRITE, EMI (SMD) (2012)
< TRANSISTOR >
Q800 8-729-920-31 TRANSISTOR DTC343TK
Q801 8-729-920-31 TRANSISTOR DTC343TK
Q803 8-729-920-31 TRANSISTOR DTC343TK
Q804 8-729-920-31 TRANSISTOR DTC343TK
< RESISTOR >
R800 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R801 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R802 1-216-805-11 METAL CHIP 47 5% 1/10W
R803 1-216-805-11 METAL CHIP 47 5% 1/10W
R805 1-216-805-11 METAL CHIP 47 5% 1/10W
R807 1-216-805-11 METAL CHIP 47 5% 1/10W
************************************************************
A-1060-648-A IO BOARD, COMPLETE
******************
< CAPACITOR >
C202 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C206 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C207 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C208 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C209 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
DMB09 ENCODER FL H/P IO
