85
HCD-BC150/BC250
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C211 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C213 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C214 1-104-662-91 ELECT 22uF 20% 25V
C215 1-104-662-91 ELECT 22uF 20% 25V
C216 1-104-662-91 ELECT 22uF 20% 25V
C217 1-104-662-91 ELECT 22uF 20% 25V
C222 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C223 1-104-662-91 ELECT 22uF 20% 25V
C227 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C228 1-126-933-11 ELECT 100uF 20% 16V
C229 1-126-933-11 ELECT 100uF 20% 16V
C230 1-126-916-11 ELECT 1000uF 20% 6.3V
C231 1-126-916-11 ELECT 1000uF 20% 6.3V
C232 1-126-916-11 ELECT 1000uF 20% 6.3V
C233 1-104-662-91 ELECT 22uF 20% 25V
C235 1-104-662-91 ELECT 22uF 20% 25V
C238 1-104-662-91 ELECT 22uF 20% 25V
C239 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C240 1-126-964-11 ELECT 10uF 20% 50V
C241 1-126-964-11 ELECT 10uF 20% 50V
C242 1-126-935-11 ELECT 470uF 20% 16V
C243 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C244 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C245 1-126-960-11 ELECT 1uF 20% 50V
C246 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C247 1-126-960-11 ELECT 1uF 20% 50V
C248 1-126-960-11 ELECT 1uF 20% 50V
C249 1-126-964-11 ELECT 10uF 20% 50V
C250 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C256 1-104-662-91 ELECT 22uF 20% 25V
C257 1-104-662-91 ELECT 22uF 20% 25V
C259 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C263 1-126-964-11 ELECT 10uF 20% 50V
C267 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C268 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C269 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C271 1-115-156-11 CERAMIC CHIP 1uF 10V
C277 1-126-934-11 ELECT 220uF 20% 16V
C278 1-104-662-91 ELECT 22uF 20% 25V
C279 1-104-662-91 ELECT 22uF 20% 25V
C280 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C281 1-115-156-11 CERAMIC CHIP 1uF 10V
C282 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C288 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
< CONNECTOR >
CN200 1-568-830-11 CONNECTOR, FFC 11P
CN201 1-779-285-11 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
CN202 1-779-279-11 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
< DIODE >
D201 8-719-988-61 DIODE 1SS355TE-17
D202 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC200 8-759-385-76 IC MC14052 BDR2
IC201 6-705-602-01 IC MM1623BFBE
IC203 8-759-710-97 IC NJM4565M-D
< JACK >
J200 1-764-593-21 JACK 2P (VIDEO/SAT)
J201 1-817-449-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
J203 1-694-920-11 TERMINAL BOARD (S TERMINAL+1P)
(MONITOR OUT)
< COIL >
L200 1-414-754-11 INDUCTOR 10uH
L207 1-414-754-11 INDUCTOR 10uH
L208 1-414-754-11 INDUCTOR 10uH
< TRANSISTOR >
Q202 8-729-901-00 TRANSISTOR DTC124EK
Q203 8-729-901-00 TRANSISTOR DTC124EK
Q211 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q212 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R203 1-216-864-11 SHORT CHIP 0
R204 1-216-864-11 SHORT CHIP 0
R212 1-216-857-11 METAL CHIP 1M 5% 1/10W
R215 1-216-857-11 METAL CHIP 1M 5% 1/10W
R216 1-216-845-11 METAL CHIP 100K 5% 1/10W
R217 1-216-845-11 METAL CHIP 100K 5% 1/10W
R218 1-216-833-11 METAL CHIP 10K 5% 1/10W
R221 1-216-845-11 METAL CHIP 100K 5% 1/10W
R222 1-216-845-11 METAL CHIP 100K 5% 1/10W
R226 1-216-845-11 METAL CHIP 100K 5% 1/10W
R227 1-216-845-11 METAL CHIP 100K 5% 1/10W
R228 1-216-845-11 METAL CHIP 100K 5% 1/10W
R229 1-216-845-11 METAL CHIP 100K 5% 1/10W
R230 1-216-864-11 SHORT CHIP 0
R231 1-218-285-11 METAL CHIP 75 5% 1/10W
R232 1-218-285-11 METAL CHIP 75 5% 1/10W
R233 1-218-285-11 METAL CHIP 75 5% 1/10W
R234 1-218-285-11 METAL CHIP 75 5% 1/10W
R235 1-216-833-11 METAL CHIP 10K 5% 1/10W
R237 1-218-285-11 METAL CHIP 75 5% 1/10W
R238 1-218-285-11 METAL CHIP 75 5% 1/10W
R244 1-216-833-11 METAL CHIP 10K 5% 1/10W
R248 1-216-833-11 METAL CHIP 10K 5% 1/10W
R251 1-216-833-11 METAL CHIP 10K 5% 1/10W
R253 1-216-837-11 METAL CHIP 22K 5% 1/10W
R254 1-216-837-11 METAL CHIP 22K 5% 1/10W
R256 1-216-837-11 METAL CHIP 22K 5% 1/10W
R257 1-216-837-11 METAL CHIP 22K 5% 1/10W
R259 1-216-841-11 METAL CHIP 47K 5% 1/10W
R260 1-216-841-11 METAL CHIP 47K 5% 1/10W
R263 1-216-833-11 METAL CHIP 10K 5% 1/10W
R267 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R268 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R275 1-216-864-11 SHORT CHIP 0
R277 1-216-864-11 SHORT CHIP 0
R284 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R285 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R286 1-216-813-11 METAL CHIP 220 5% 1/10W
R290 1-216-849-11 METAL CHIP 220K 5% 1/10W
R292 1-216-809-11 METAL CHIP 100 5% 1/10W
