86
HCD-BC150/BC250
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R294 1-216-849-11 METAL CHIP 220K 5% 1/10W
R295 1-216-813-11 METAL CHIP 220 5% 1/10W
R296 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R297 1-216-833-11 METAL CHIP 10K 5% 1/10W
R298 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R299 1-216-833-11 METAL CHIP 10K 5% 1/10W
R300 1-216-833-11 METAL CHIP 10K 5% 1/10W
R301 1-216-833-11 METAL CHIP 10K 5% 1/10W
R302 1-216-837-11 METAL CHIP 22K 5% 1/10W
R303 1-216-837-11 METAL CHIP 22K 5% 1/10W
R305 1-216-833-11 METAL CHIP 10K 5% 1/10W
************************************************************
1-861-264-11 LF BOARD
********
< CAPACITOR >
0 C903 1-117-916-51 FILM 0.22uF 10% 275V
< CONNECTOR >
CN900 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN901 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P
< LINE FILTER >
0 LF901 1-456-082-11 COIL, LINE FILTER
************************************************************
A-1060-645-A MAIN BOARD, COMPLETE (150)
A-1067-097-A MAIN BOARD, COMPLETE (250)
**************************
< CAPACITOR >
C506 1-115-156-11 CERAMIC CHIP 1uF 10V
C507 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C508 1-115-156-11 CERAMIC CHIP 1uF 10V
C509 1-126-960-11 ELECT 1uF 20% 50V
C510 1-126-960-11 ELECT 1uF 20% 50V
C511 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C514 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C518 1-126-964-11 ELECT 10uF 20% 50V
C522 1-104-658-91 ELECT 100uF 20% 10V
C524 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C525 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C526 1-126-947-11 ELECT 47uF 20% 35V
C527 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C528 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C529 1-126-964-11 ELECT 10uF 20% 50V
C530 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C531 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C532 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C533 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C534 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C535 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C536 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C537 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C538 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C539 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C540 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C541 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C542 1-126-923-91 ELECT 220uF 20% 10V
C543 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C544 1-126-964-11 ELECT 10uF 20% 50V
C545 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C546 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C547 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C549 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C550 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C551 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C552 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C553 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C554 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C555 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C556 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C557 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C558 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C559 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C560 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C561 1-126-924-11 ELECT 330uF 20% 10V
C562 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C563 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C564 1-126-964-11 ELECT 10uF 20% 50V
C566 1-115-156-11 CERAMIC CHIP 1uF 10V
C568 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C569 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C570 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C571 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C572 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C573 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C574 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C575 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C576 1-126-964-11 ELECT 10uF 20% 50V
C577 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C578 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C579 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C581 1-104-905-11 CAPACITOR 0.22F 5.5V
C582 1-104-658-91 ELECT 100uF 20% 10V
C583 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C584 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C586 1-104-658-91 ELECT 100uF 20% 10V
C587 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C588 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C589 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C590 1-104-658-91 ELECT 100uF 20% 10V
C591 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C592 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C593 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C594 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C595 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C596 1-126-947-11 ELECT 47uF 20% 35V
C597 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C598 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C599 1-126-923-91 ELECT 220uF 20% 10V
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
IO LF MAIN
