HCD-BC150/BC250
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< COMPOSITION CIRCUIT BLOCK >
RB501 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB502 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB503 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB504 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB505 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB506 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB507 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB508 1-233-411-11 RES, CHIP NETWORK 220 (3216)
RB509 1-233-411-11 RES, CHIP NETWORK 220 (3216)
RB510 1-233-411-11 RES, CHIP NETWORK 220 (3216)
RB901 1-236-908-11 RES, CHIP NETWORK 10K
RB902 1-236-908-11 RES, CHIP NETWORK 10K
RB903 1-236-908-11 RES, CHIP NETWORK 10K
RB904 1-236-908-11 RES, CHIP NETWORK 10K
< VIBRATOR >
X500 1-795-843-11 VIBRATOR, CRYSTAL (12.288MHz)
X501 1-813-325-11 VIBRATOR, CRYSTAL (13.90MHz)
X502 1-795-058-21 VIBRATOR, CERAMIC (5MHz)
************************************************************
MOTOR BOARD
*************
< SWITCH >
S761 1-786-704-11 SWITCH, LEVER (SUB TRAY OUT)
************************************************************
A-4752-728-A PANEL BOARD, COMPLETE
**********************
4-255-281-01 LED HOLDER
< CAPACITOR >
C817 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C818 1-126-964-11 ELECT 10uF 20% 50V
C819 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C821 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C823 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C826 1-124-234-00 ELECT 22uF 20% 10V
C830 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C835 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C836 1-119-943-91 ELECT 47uF 20% 50V
C837 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C860 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C861 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C862 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN800 1-779-556-21 CONNECTOR, FFC (LIF (NON-ZIF)) 19P
CN801 1-568-828-11 CONNECTOR, FFC 9P
< DIODE >
D803 6-500-522-01 DIODE 10EDB40-TA1B2
D806 8-719-056-13 DIODE SML79423C-TP15 (DISC 1)
D807 8-719-056-13 DIODE SML79423C-TP15 (DISC 2)
D808 8-719-056-13 DIODE SML79423C-TP15 (DISC 3)
D809 8-719-056-13 DIODE SML79423C-TP15 (DISC 4)
D810 8-719-988-61 DIODE 1SS355TE-17
D811 8-719-988-61 DIODE 1SS355TE-17
D812 8-719-056-13 DIODE SML79423C-TP15 (DISC 5)
D813 8-719-988-61 DIODE 1SS355TE-17
D814 8-719-988-61 DIODE 1SS355TE-17
D815 8-719-069-56 DIODE UDZSTE-176.2B
D816 6-500-940-01 DIODE SEL6E14C-STP5 (BACK LIGHT)
D817 6-500-940-01 DIODE SEL6E14C-STP5 (BACK LIGHT)
D818 6-500-940-01 DIODE SEL6E14C-STP5 (BACK LIGHT)
D819 6-500-940-01 DIODE SEL6E14C-STP5 (BACK LIGHT)
D820 6-500-940-01 DIODE SEL6E14C-STP5 (BACK LIGHT)
D821 6-500-940-01 DIODE SEL6E14C-STP5 (BACK LIGHT)
< FERRITE BEAD >
FB804 1-216-864-11 SHORT CHIP 0
< IC >
IC802 6-701-888-01 IC BU2152FS
< COIL >
L804 1-410-671-31 INDUCTOR 47uH
L806 1-469-144-21 FERRITE, EMI (SMD) (2012)
< TRANSISTOR >
Q806 8-729-034-51 TRANSISTOR KTC3875
Q807 8-729-034-51 TRANSISTOR KTC3875
Q808 6-550-065-01 TRANSISTOR CPH5504-TL-E
Q820 8-729-038-68 TRANSISTOR KRC103S
Q821 8-729-038-68 TRANSISTOR KRC103S
Q822 8-729-038-68 TRANSISTOR KRC103S
< RESISTOR >
R812 1-216-864-11 SHORT CHIP 0
R817 1-216-821-11 METAL CHIP 1K 5% 1/10W
R818 1-216-833-11 METAL CHIP 10K 5% 1/10W
R821 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R823 1-216-841-11 METAL CHIP 47K 5% 1/10W
R824 1-216-821-11 METAL CHIP 1K 5% 1/10W
R825 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R826 1-216-812-11 METAL CHIP 180 5% 1/10W
R827 1-216-812-11 METAL CHIP 180 5% 1/10W
R828 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R829 1-216-812-11 METAL CHIP 180 5% 1/10W
R830 1-216-812-11 METAL CHIP 180 5% 1/10W
R831 1-216-812-11 METAL CHIP 180 5% 1/10W
R832 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R833 1-216-812-11 METAL CHIP 180 5% 1/10W
R834 1-216-812-11 METAL CHIP 180 5% 1/10W
R835 1-216-812-11 METAL CHIP 180 5% 1/10W
R836 1-216-833-11 METAL CHIP 10K 5% 1/10W
R837 1-216-812-11 METAL CHIP 180 5% 1/10W
R838 1-216-812-11 METAL CHIP 180 5% 1/10W
R839 1-216-839-11 METAL CHIP 33K 5% 1/10W
R840 1-216-809-11 METAL CHIP 100 5% 1/10W
R841 1-216-809-11 METAL CHIP 100 5% 1/10W
R842 1-216-809-11 METAL CHIP 100 5% 1/10W
R843 1-216-809-11 METAL CHIP 100 5% 1/10W
