90
HCD-BC150/BC250
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R844 1-216-837-11 METAL CHIP 22K 5% 1/10W
R845 1-216-821-11 METAL CHIP 1K 5% 1/10W
R846 1-216-809-11 METAL CHIP 100 5% 1/10W
R847 1-216-833-11 METAL CHIP 10K 5% 1/10W
R848 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R849 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R850 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R851 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R852 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R855 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R856 1-216-837-11 METAL CHIP 22K 5% 1/10W
R859 1-216-821-11 METAL CHIP 1K 5% 1/10W
R861 1-216-864-11 SHORT CHIP 0
R866 1-216-815-11 METAL CHIP 330 5% 1/10W
R869 1-216-815-11 METAL CHIP 330 5% 1/10W
R873 1-216-815-11 METAL CHIP 330 5% 1/10W
< SWITCH >
S801 1-771-608-21 SWITCH, TACTILE (A (DISC 1))
S802 1-771-608-21 SWITCH, TACTILE (A (DISC 2))
S803 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S804 1-771-608-21 SWITCH, TACTILE (DISC 1)
S805 1-771-608-21 SWITCH, TACTILE (DISC 2)
S806 1-771-608-21 SWITCH, TACTILE (DISC 3)
S807 1-762-875-21 SWITCH, KEYBOARD (VOLUME -)
S808 1-762-875-21 SWITCH, KEYBOARD (> PRESET +)
S809 1-762-875-21 SWITCH, KEYBOARD (H)
S810 1-762-875-21 SWITCH, KEYBOARD (x)
S811 1-771-608-21 SWITCH, TACTILE (DISC 4)
S812 1-771-608-21 SWITCH, TACTILE (DISC 5)
S813 1-762-875-21 SWITCH, KEYBOARD (. PRESET -)
S814 1-771-608-21 SWITCH, TACTILE (A (DISC 5))
S815 1-762-875-21 SWITCH, KEYBOARD (VOLUME +)
S816 1-771-608-21 SWITCH, TACTILE (A (DISC 4))
S817 1-762-875-21 SWITCH, KEYBOARD (X)
S818 1-771-608-21 SWITCH, TACTILE (A (DISC 3))
< TRANSFORMER >
T801 1-443-172-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
1-861-265-11 POWER SW BOARD
****************
< CAPACITOR >
C805 1-126-795-11 ELECT 10uF 20% 50V
C807 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN805 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE) 5P
< DIODE >
D802 6-500-809-01 DIODE SELU5223C-STP15 (STAND BY)
< IC >
IC800 8-759-826-34 IC NJL74H400A ( )
< RESISTOR >
R804 1-216-805-11 METAL CHIP 47 5% 1/10W
R811 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R814 1-216-805-11 METAL CHIP 47 5% 1/10W
< SWITCH >
S800 1-762-875-21 SWITCH, KEYBOARD (?/1)
************************************************************
SENSOR BOARD
**************
< IC >
IC751 8-759-989-76 IC RPR-359F
************************************************************
SPK BOARD
**********
< CAPACITOR >
C340 1-162-294-31 CERAMIC 0.001uF 10% 50V
C341 1-162-294-31 CERAMIC 0.001uF 10% 50V
C342 1-162-294-31 CERAMIC 0.001uF 10% 50V
C343 1-162-294-31 CERAMIC 0.001uF 10% 50V
C481 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C482 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C483 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C484 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C485 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C486 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C487 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C488 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C489 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C490 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C491 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C492 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CN309 1-564-241-11 PIN, CONNECTOR (3.96mm PITCH) 4P
CN311 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CN312 1-691-766-21 PLUG (MICRO CONNECTOR) 4P
< TERMINAL >
GP306 1-537-770-21 TERMINAL BOARD, GROUND
GP307 1-537-770-21 TERMINAL BOARD, GROUND
TB301 1-694-998-21 TERMINAL BOARD (SPEAKER)
************************************************************
SW (1) BOARD
************
< SWITCH >
S721 1-786-084-11 SWITCH, DETECTION (MAIN TRAY IN/OUT)
************************************************************
PANEL POWER SW SENSOR SPK SW (1)
