Sony HCD-BC150 - SW (2) BOARD; TRANSLATION

91
HCD-BC150/BC250
Ref. No. Part No. Description Remark
SW (2) BOARD
************
< SWITCH >
S731 1-786-382-11 SWITCH, PUSH (1 KEY) (SUB TRAY IN)
************************************************************
A-4750-232-A TRANSLATION BOARD, COMPLETE
****************************
< CAPACITOR >
C701 1-126-786-11 ELECT 47uF 20% 16V
C702 1-126-791-11 ELECT 10uF 20% 35V
C761 1-162-306-11 CERAMIC 0.01uF 20% 16V
C762 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN701 1-779-558-21 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
< DIODE >
D701 8-719-921-40 DIODE MTZJ-4.7C
D711 8-719-982-10 DIODE MTZJ-4.3A
< IC >
IC701 8-759-598-69 IC BA6956AN
IC711 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q751 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R701 1-249-415-11 CARBON 680 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-249-415-11 CARBON 680 5% 1/4W
R712 1-247-807-31 CARBON 100 5% 1/4W
R751 1-247-806-11 CARBON 91 5% 1/4W
R752 1-249-429-11 CARBON 10K 5% 1/4W
R753 1-249-429-11 CARBON 10K 5% 1/4W
R754 1-249-430-11 CARBON 12K 5% 1/4W
R755 1-249-429-11 CARBON 10K 5% 1/4W
************************************************************
MISCELLANEOUS
**************
5 1-763-861-12 FAN, DC
6 1-828-962-11 WIRE (FLAT TYPE) (11 CORE)
103 1-828-954-11 WIRE (FLAT TYPE) (9 CORE)
0 105 1-783-531-72 CORD, POWER
0 108 1-468-836-13 REGULATOR, SWITCHING
M761 A-4713-174-A MOTOR (81) ASSY (LD/ST MOTOR)
M762 A-4713-174-A MOTOR (81) ASSY (BU U/D MOTOR)
S771 1-478-552-11 ENCODER, ROTARY (MD)
S781 1-478-551-11 ENCODER, ROTARY (ST U/D ENCODER)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
SW (2) TRANSLATION
