51
HCD-BC150/BC250
Pin No. Pin Name I/O Description
53 XSRQ I
“DVD mode: Serial data request signal input from the DVD system processor
SACD mode: Serial data request signal input from the DSD decoder”
54 HINT O Not used
55 XS16 O Not used
56 HA1 I Not used
57 XPDI I/O Not used
58 VDDS — Power supply terminal (+5V) (digital system)
59, 60 HA0, HA2 I Not used
61 VSS — Ground terminal (digital system)
62, 63 HCS0, HCS1 I Not used
64 VDD — Power supply terminal (+3.3V) (digital system)
65 DASP I/O Not used
66 to 69 MDB0 to MDB3 I/O Two-way data bus with the D-RAM
70 VSS — Ground terminal (digital system)
71 MDB4 I/O Two-way data bus with the D-RAM
72 VDD5V — Power supply terminal (+5V)
73 to 75 MDB5 to MDB7 I/O Two-way data bus with the D-RAM
76 XMWR O Write enable signal output to the D-RAM
77 VDD — Power supply terminal (+3.3V) (digital system)
78 XRAS O Row address strobe signal output to the D-RAM
79, 80 MA0, MA1 O Address signal output to the D-RAM
81 VSS — Ground terminal (digital system)
82 to 87 MA2 to MA7 O Address signal output to the D-RAM
88 VDD — Power supply terminal (+3.3V) (digital system)
89 MA8 O Address signal output to the D-RAM
90 VSS — Ground terminal (digital system)
91 MA9 O Address signal output to the D-RAM
92 MNT1 O EEPROM ready signal output to the mechanism controller
93 MNT2 O
Operation clock signal output for PSP physical disc mark detection to DSD decoder
94 XMOE O Output enable signal output to the D-RAM
95 XCAS O Column address strobe signal output to the D-RAM
96, 97 MDB8, MDB9 I/O Two-way data bus with the D-RAM
98 VSS — Ground terminal (digital system)
99 MDBA I/O Two-way data bus with the D-RAM
100 VDD — Power supply terminal (+3.3V) (digital system)
101, 102 MDBB, MDBC I/O Two-way data bus with the D-RAM
103 VDD5V — Power supply terminal (+5V)
104 to 106 MDBD to MDBF I/O Two-way data bus with the D-RAM
107 GFS O Guard frame sync signal output to the mechanism controller
108 VSS — Ground terminal (digital system)
109 APEO O Absolute phase error signal output
110 VDD — Power supply terminal (+3.3V) (digital system)
111 DASYO O RF binary signal output
112 GNDA5 — Ground terminal (analog system)
113, 114 ASF1, AFS2 — Filter connected terminal for selection the constant asymmetry compensation
115 DASYI I Analog signal input after integrated from the RF binary signal
116 RFDCC I Input terminal for adjusting DC cut high-pass filter for RF signal Not used
Ver 1.3
