101
HCD-C450
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< RESISTOR >
R002 1-216-809-11 METAL CHIP 100 5% 1/16W
R003 1-216-809-11 METAL CHIP 100 5% 1/16W
R005 1-216-845-11 METAL CHIP 100K 5% 1/16W
R006 1-216-838-11 METAL CHIP 27K 5% 1/16W
R007 1-216-803-11 METAL CHIP 33 5% 1/16W
R008 1-216-803-11 METAL CHIP 33 5% 1/16W
R009 1-216-821-11 METAL CHIP 1K 5% 1/16W
R010 1-216-841-11 METAL CHIP 47K 5% 1/16W
R011 1-216-809-11 METAL CHIP 100 5% 1/16W
R020 1-216-803-11 METAL CHIP 33 5% 1/16W
R023 1-216-803-11 METAL CHIP 33 5% 1/16W
R025 1-216-841-11 METAL CHIP 47K 5% 1/16W
R029 1-216-809-11 METAL CHIP 100 5% 1/16W
R037 1-216-834-11 METAL CHIP 12K 5% 1/16W
R038 1-216-861-11 METAL CHIP 2.2M 5% 1/16W
R045 1-216-809-11 METAL CHIP 100 5% 1/16W
**************************************************************
1-675-726-21 SENSOR BOARD
**************
< CONNECTOR >
CN708 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D704 8-719-055-84 DIODE GL528VS1
< RESISTOR >
R711 1-249-415-11 CARBON 680 5% 1/4W F
**************************************************************
1-675-727-21 SENSOR 2 BOARD
***************
4-964-461-02 HOLDER (SENSOR)
< TRANSISTOR >
Q703 8-729-921-53 PHOTO TRANSISTOR PT483F1
**************************************************************
1-682-000-13 SW 1179 BOARD
**************
< CONNECTOR >
CN810 1-506-481-11 PIN, CONNECTOR 2P
< RESISTOR >
R800 1-216-815-11 METAL CHIP 330 5% 1/16W
R801 1-216-817-11 METAL CHIP 470 5% 1/16W
R802 1-216-819-11 METAL CHIP 680 5% 1/16W
R803 1-216-821-11 METAL CHIP 1K 5% 1/16W
< SWITCH >
S801 1-786-220-11 SWITCH, KEY BOARD (stop)
S802 1-786-220-11 SWITCH, KEY BOARD (pause)
S803 1-786-220-11 SWITCH, KEY BOARD (play)
S804 1-786-220-11 SWITCH, KEY BOARD (PRESET +/NEXT >)
S805 1-786-220-11 SWITCH, KEY BOARD (PRESET –/. PREV)
**************************************************************
MISCELLANEOUS
**************
05 1-696-169-11 CORD, POWER (EXCEPT US,CND,AUS,MX)
05 1-696-848-41 CORD, POWER (AUS)
05 1-783-531-72 CORD, POWER (US,CND)
05 1-824-090-11 POWER CORD (MX)
51 A-4726-404-A TUNER (A) MOUNTED PC BOARD (US, CND)
51 A-4726-588-A TUNER (A) MOUNTED PC BOARD (AUS)
51 A-4726-905-A TUNER (A) MOUNTED PC BOARD
(EXCEPT US,CND,AUS)
52 1-823-082-11 CABLE, FLEXIBLE FLAT (13 CORE)
54 1-823-124-11 CABLE, FLEXIBLE FLAT (29 CORE)
55 1-823-355-11 CABLE, FLEXIBLE FLAT (13 CORE)
62 1-823-080-11 CABLE, FLEXIBLE FLAT (25 CORE)
63 1-823-083-11 CABLE, FLEXIBLE FLAT (9 CORE)
64 1-823-084-21 CABLE, FLEXIBLE FLAT (17 CORE)
65 1-823-125-21 CABLE, FLEXIBLE FLAT (12 CORE)
114 1-823-081-11 CABLE, FLEXIBLE FLAT (17 CORE)
554 1-823-085-11 CABLE, FLEXIBLE FLAT (9 CORE)
555 1-823-072-11 CABLE, FLEXIBLE FLAT 26P
0558 8-820-144-06 OPTICAL PICK-UP KHM-240AAA
0F901 1-533-453-11 FUSE, GLASS TUBE (DIA. 5) (5A/125V)
(US,CND,MX)
0F901 1-533-470-11 FUSE, GLASS TUBE (DIA. 5) (T3.15AL/25OV)
(EXCEPT US,CND,MX)
M701 X-4950-341-1 MOTOR (CLAMP) ASSY (CLAMP)
M702 1-763-790-11 MOTOR, DC (LOADING)
S707 1-418-045-01 ENCODER, ROTARY (DISC TRAY ADDRESS DETECT)
0S901 1-786-210-11 SWITCH, POWER (POWER)
SENSOR 2 SW 1179RF-240 SENSOR
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
Ver 1.3 2003.05
