Sony HCD-C450 - SECTION 1 GENERAL; Index to Parts and Controls

5
HCD-C450
SECTION 1
GENERAL
This section is extracted
from instruction manual.
Index to Parts and Controls
Front Panel
Rear Panel
OUT
IN
L
R
IN
L
R
OPTICAL
DIGITAL
IN
VIDEO
S VIDEO
(DVD ONLY)
Y
P
B /C B P R /C R
FRONT R
FRONT L
CENTER
SPEAKER
REAR R
REAR L
WOOFER
COAXIAL
AM
FM
75Π
AUDIO 1 AUDIO 2
MONITOR OUT
COMPONENT VIDEO OUT
For more information, refer to the pages indicated in parentheses.
1 POWER switch/indicator (32)
2 DISC 1 (play) / A (open/close)-DISC 5
(play) / A (open/close) (32)
3 Front panel display (12)
4 ./> PREV/NEXT, PRESET +/–
(30, 33)
5 H (play) (32)
6 X (pause) (33)
7 x (stop) (33)
8 PHONES jack (32)
9 VOLUME control (32)
q; SOUND FIELD +/– (49)
qa DISPLAY (49, 64)
qs BAND (30)
qd FUNCTION (63)
qf
(remote sensor) (18)
qg Disc tray (32)
1 AM antenna (21)
2 AUDIO 1 jacks (23)
3 AUDIO 2 jacks (23)
4 DIGITAL IN (OPTICAL) jack (24)
5 MONITOR OUT (VIDEO/S VIDEO)
jacks (23)
6 COMPONENT VIDEO OUT jacks (23)
7 SPEAKER jacks (19)
8 FM 75Ω COAXIAL antenna jack (21)
