HCD-C450
SECTION 7
ELECTRICAL PARTS LIST
Note:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µPB...,
uPC...: µ PC..., uPD...: µ PD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
• CAPACITORS
uF : µ F
• COILS
uH : µ H
•Abbreviation
AUS: Australian model.
CND : Canadian model.
E12 : 220V-240V AC in E model.
E32 : 110V-240V AC (without VS) in E model.
EA : Saudi Arabia model.
MX : Mexican model.
SP : Singapore model.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMP
A-4729-819-A AMP BOARD, COMPLETE (EXCEPT US,CND,MX)
A-4676-743-A AMP BOARD, COMPLETE (US,CND,MX)
********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C300 1-115-819-11 ELECT 2200uF 20.00% 35V
C301 1-126-965-91 ELECT 22uF 20.00% 50V
C302 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C303 1-136-157-00 FILM 0.022uF 5% 50V
C304 1-136-157-00 FILM 0.022uF 5% 50V
C305 1-136-165-00 FILM 0.1uF 5% 50V
C306 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C307 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C308 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C309 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C310 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C311 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C312 1-104-665-11 ELECT 100uF 20.00% 10V
C313 1-136-165-00 FILM 0.1uF 5% 50V
C316 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C317 1-126-948-11 ELECT 100uF 20.00% 35V
C318 1-104-665-11 ELECT 100uF 20.00% 10V
C319 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C320 1-104-665-11 ELECT 100uF 20.00% 10V
C323 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C324 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C325 1-104-665-11 ELECT 100uF 20.00% 10V
C326 1-126-947-11 ELECT 47uF 20.00% 10V
C327 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C328 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C329 1-126-934-11 ELECT 220uF 20.00% 10V
C330 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C331 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C332 1-136-157-00 FILM 0.022uF 5% 50V
C333 1-136-157-00 FILM 0.022uF 5% 50V
C334 1-136-165-00 FILM 0.1uF 5% 50V
C335 1-136-165-00 FILM 0.1uF 5% 50V
C336 1-104-665-11 ELECT 100uF 20.00% 10V
C337 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C341 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C342 1-126-948-11 ELECT 100uF 20.00% 35V
C343 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C344 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C345 1-104-665-11 ELECT 100uF 20.00% 10V
C348 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C349 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C350 1-104-665-11 ELECT 100uF 20.00% 10V
C351 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C352 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C353 1-136-157-00 FILM 0.022uF 5% 50V
C354 1-136-157-00 FILM 0.022uF 5% 50V
C355 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C356 1-136-165-00 FILM 0.1uF 5% 50V
C357 1-136-165-00 FILM 0.1uF 5% 50V
C358 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C359 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C362 1-104-665-11 ELECT 100uF 20.00% 10V
C363 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C364 1-126-948-11 ELECT 100uF 20.00% 35V
C365 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C368 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C372 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C373 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C374 1-136-157-00 FILM 0.022uF 5% 50V
C375 1-136-157-00 FILM 0.022uF 5% 50V
C376 1-136-165-00 FILM 0.1uF 5% 50V
C377 1-136-165-00 FILM 0.1uF 5% 50V
C378 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C381 1-104-665-11 ELECT 100uF 20.00% 10V
C382 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C383 1-126-948-11 ELECT 100uF 20.00% 35V
C384 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C387 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C388 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C389 1-104-665-11 ELECT 100uF 20.00% 10V
C390 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C391 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C392 1-104-665-11 ELECT 100uF 20.00% 10V
C393 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C394 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C395 1-136-157-00 FILM 0.022uF 5% 50V
C396 1-136-157-00 FILM 0.022uF 5% 50V
C397 1-136-165-00 FILM 0.1uF 5% 50V
C398 1-136-165-00 FILM 0.1uF 5% 50V
C399 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
