Sony HCD-C450 - DVD Board Parts List

84
HCD-C450
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
AMP
C402 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C403 1-126-948-11 ELECT 100uF 20.00% 35V
C404 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C405 1-104-665-11 ELECT 100uF 20.00% 10V
C408 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C409 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C410 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C411 1-136-157-00 FILM 0.022uF 5% 50V
C412 1-136-157-00 FILM 0.022uF 5% 50V
C413 1-136-165-00 FILM 0.1uF 5% 50V
C414 1-136-165-00 FILM 0.1uF 5% 50V
C415 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C416 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C419 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C420 1-126-948-11 ELECT 100uF 20.00% 35V
C421 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C422 1-104-665-11 ELECT 100uF 20.00% 10V
C425 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C432 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C433 1-164-230-11 CERAMIC CHIP 220PF 5.00% 50V
C434 1-164-230-11 CERAMIC CHIP 220PF 5.00% 50V
C441 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C442 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C443 1-163-234-11 CERAMIC CHIP 20PF 5.00% 50V
(US,CND,MX)
C443 1-163-243-11 CERAMIC CHIP 47PF 5.00% 50V
(EXCEPT US,CND,MX)
C451 1-136-177-00 FILM 1uF 5.00% 50V
C452 1-136-177-00 FILM 1uF 5.00% 50V
C453 1-136-177-00 FILM 1uF 5.00% 50V
C454 1-136-177-00 FILM 1uF 5.00% 50V
C455 1-136-177-00 FILM 1uF 5.00% 50V
C456 1-136-177-00 FILM 1uF 5.00% 50V
C457 1-136-177-00 FILM 1uF 5.00% 50V
C458 1-136-177-00 FILM 1uF 5.00% 50V
C459 1-136-177-00 FILM 1uF 5.00% 50V
C460 1-136-177-00 FILM 1uF 5.00% 50V
C461 1-136-177-00 FILM 1uF 5.00% 50V
C462 1-136-177-00 FILM 1uF 5.00% 50V
C474 1-126-934-11 ELECT 220uF 20.00% 16V
C484 1-126-934-11 ELECT 220uF 20.00% 16V
< CONNECTOR >
CN301 1-779-280-11 CONNECTOR,FFC (LIF (NON-ZIF) ) 12P
CN305 1-793-600-11 CONNECTOR, FFC/FPC (ZIF) 17P
* CN309 1-506-987-11 PIN, CONNECTOR (PC BOARD) 5P
< DIODE >
D310 8-719-073-82 DIODE SFPB-76V
D311 8-719-073-82 DIODE SFPB-76V
D312 8-719-073-82 DIODE SFPB-76V
D313 8-719-073-82 DIODE SFPB-76V
D314 8-719-073-82 DIODE SFPB-76V
D315 8-719-073-82 DIODE SFPB-76V
D320 8-719-073-82 DIODE SFPB-76V
D321 8-719-073-82 DIODE SFPB-76V
D322 8-719-073-82 DIODE SFPB-76V
D323 8-719-073-82 DIODE SFPB-76V
D324 8-719-073-82 DIODE SFPB-76V
D325 8-719-073-82 DIODE SFPB-76V
D330 6-500-131-01 DIODE LI116
D331 6-500-131-01 DIODE LI116
D332 6-500-131-01 DIODE LI116
D333 6-500-131-01 DIODE LI116
D334 6-500-131-01 DIODE LI116
D335 6-500-131-01 DIODE LI116
D340 6-500-131-01 DIODE LI116
D341 6-500-131-01 DIODE LI116
D342 6-500-131-01 DIODE LI116
D343 6-500-131-01 DIODE LI116
D344 6-500-131-01 DIODE LI116
D345 6-500-131-01 DIODE LI116
D351 8-719-404-50 DIODE MA111-TX
D370 6-500-060-01 DIODE P6SMB36AT3
D371 6-500-060-01 DIODE P6SMB36AT3
D372 6-500-060-01 DIODE P6SMB36AT3
D373 6-500-060-01 DIODE P6SMB36AT3
D374 6-500-060-01 DIODE P6SMB36AT3
D375 6-500-060-01 DIODE P6SMB36AT3
D380 6-500-060-01 DIODE P6SMB36AT3
D381 6-500-060-01 DIODE P6SMB36AT3
D382 6-500-060-01 DIODE P6SMB36AT3
D383 6-500-060-01 DIODE P6SMB36AT3
D384 6-500-060-01 DIODE P6SMB36AT3
D385 6-500-060-01 DIODE P6SMB36AT3
< TERMINAL >
EB301 1-537-770-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB300 1-469-760-21 INDUCTOR 0UH
FB301 1-469-760-21 INDUCTOR 0UH
FB303 1-400-160-51 INDUCTOR 0UH
FB304 1-469-760-21 INDUCTOR 0UH
FB307 1-469-760-21 INDUCTOR 0UH
FB308 1-469-760-21 INDUCTOR 0UH
FB309 1-400-160-51 INDUCTOR 0UH
FB312 1-400-160-51 INDUCTOR 0UH
FB313 1-400-160-51 INDUCTOR 0UH
FB314 1-469-760-21 INDUCTOR 0UH
FB315 1-469-760-21 INDUCTOR 0UH
FB318 1-400-160-51 INDUCTOR 0UH
FB320 1-400-160-51 INDUCTOR 0UH
FB365 1-400-160-51 INDUCTOR 0uH
< IC >
IC300 8-759-834-29 IC MC74VHC1G04DFT1
IC301 6-701-741-01 IC CXD9646A
IC302 8-759-533-85 IC BA05FP-E2
IC303 8-759-583-47 IC uPC2933T-E2
IC304 6-701-741-01 IC CXD9646A
IC305 6-700-279-01 IC CXD9634AQ
IC306 6-701-741-01 IC CXD9646A
IC307 6-701-741-01 IC CXD9646A
IC308 6-700-279-01 IC CXD9634AQ
IC309 6-701-741-01 IC CXD9646A
