85
HCD-C450
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
AMP
IC310 6-700-279-01 IC CXD9634AQ
IC311 6-701-741-01 IC CXD9646A
IC312 8-759-834-30 IC MC74VHC1G08DFT1
< TERMINAL >
J401 1-694-656-11 TERMINAL BOARD (6CH SPEAKER)
< COIL >
L302 1-412-939-11 INDUCTOR 1uH
L401 1-424-777-11 INDUCTOR 10uH
L402 1-424-777-11 INDUCTOR 10uH
L403 1-424-777-11 INDUCTOR 10uH
L404 1-424-777-11 INDUCTOR 10uH
L405 1-424-777-11 INDUCTOR 10uH
L406 1-424-777-11 INDUCTOR 10uH
< TRANSISTOR >
Q301 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R300 1-216-833-11 METAL CHIP 10K 5% 1/16W
R301 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R302 1-216-857-11 METAL CHIP 1M 5% 1/16W
R303 1-216-833-11 METAL CHIP 10K 5% 1/16W
R304 1-216-809-11 METAL CHIP 100 5% 1/16W
R305 1-216-809-11 METAL CHIP 100 5% 1/16W
R307 1-216-809-11 METAL CHIP 100 5% 1/16W
R308 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R309 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R310 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R311 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R312 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R313 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R315 1-216-809-11 METAL CHIP 100 5% 1/16W
R316 1-216-809-11 METAL CHIP 100 5% 1/16W
R317 1-216-809-11 METAL CHIP 100 5% 1/16W
R318 1-216-809-11 METAL CHIP 100 5% 1/16W
R319 1-216-809-11 METAL CHIP 100 5% 1/16W
R320 1-216-809-11 METAL CHIP 100 5% 1/16W
R321 1-216-809-11 METAL CHIP 100 5% 1/16W
R322 1-216-803-11 METAL CHIP 33 5% 1/16W
R325 1-216-801-11 METAL CHIP 22 5% 1/16W
R330 1-216-809-11 METAL CHIP 100 5% 1/16W
R333 1-216-809-11 METAL CHIP 100 5% 1/16W
R334 1-216-820-11 METAL CHIP 820 5% 1/16W
R335 1-216-809-11 METAL CHIP 100 5% 1/16W
R336 1-216-820-11 METAL CHIP 820 5% 1/16W
R337 1-216-833-11 METAL CHIP 10K 5% 1/16W
R338 1-216-295-00 SHORT 0
R339 1-216-814-11 METAL CHIP 270 5% 1/16W
R340 1-216-814-11 METAL CHIP 270 5% 1/16W
R341 1-216-814-11 METAL CHIP 270 5% 1/16W
R342 1-216-814-11 METAL CHIP 270 5% 1/16W
R343 1-216-809-11 METAL CHIP 100 5% 1/16W
R344 1-216-814-11 METAL CHIP 270 5% 1/16W
R346 1-216-295-00 SHORT 0
R347 1-216-295-00 SHORT 0
R348 1-216-809-11 METAL CHIP 100 5% 1/16W
R349 1-216-809-11 METAL CHIP 100 5% 1/16W
R350 1-216-809-11 METAL CHIP 100 5% 1/16W
R370 1-218-484-11 RES-CHIP 750 5% 1/10W
R410 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R411 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R415 1-216-833-11 METAL CHIP 10K 5% 1/16W
R420 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R421 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R476 1-216-295-00 SHORT 0
R486 1-216-295-00 SHORT 0
< RELAY >
RY301 1-515-920-11 RELAY (24V)
RY302 1-515-920-11 RELAY (24V)
RY303 1-515-920-11 RELAY (24V)
< VIBRATOR >
X300 1-795-286-21 VIBRATOR, CRYSTAL (49.152MHz)
**************************************************************
1-675-729-21 CLAMP MOTOR BOARD
*******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C702 1-126-964-11 ELECT 10uF 20.00% 50V
C706 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C711 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< CONNECTOR >
* CN712 1-568-954-11 PIN, CONNECTOR 5P
< DIODE >
D701 8-719-109-69 DIODE MTZJ-T-77-3.6B
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W F
**************************************************************
COMPONENT BOARD
*****************
< CAPACITOR >
C742 1-126-933-11 ELECT 100uF 20.00% 16V
C743 1-124-234-00 ELECT 22uF 20% 16V
C744 1-126-933-11 ELECT 100uF 20.00% 16V
C745 1-128-551-11 ELECT 22uF 20.00% 25V
C746 1-126-933-11 ELECT 100uF 20.00% 16V
C747 1-128-551-11 ELECT 22uF 20.00% 25V
C748 1-162-918-11 CERAMIC CHIP 18PF 5.00% 50V
C749 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
CLAMP MOTOR COMPONENT
