Sony HCD-C450 - I;O Board Parts List

86
HCD-C450
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< IC >
IC703 8-759-522-11 IC BA7660FS-E2
< JACK >
J666 1-815-814-21 JACK, PIN 3P (COMPONENT VIDEO OUT)
< RESISTOR >
R729 1-218-285-11 RES-CHIP 75 5% 1/10W
R730 1-218-285-11 RES-CHIP 75 5% 1/10W
R731 1-218-285-11 RES-CHIP 75 5% 1/10W
**************************************************************
1-675-722-21 CONNECTOR BOARD
*****************
< CONNECTOR >
CN701 1-770-169-11 CONNECTOR, FFC/FPC 17P
< TRANSISTOR >
Q701 8-729-029-66 TRANSISTOR RT1N141S-TP
< RESISTOR >
R707 1-249-424-11 CARBON 3.9K 5% 1/4W F
R708 1-249-417-11 CARBON 1K 5% 1/4W F
R709 1-249-429-11 CARBON 10K 5% 1/4W
**************************************************************
1-681-998-13 DDCON 1179 BOARD
*****************
< CAPACITOR >
C820 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C821 1-126-964-11 ELECT 10uF 20.00% 50V
C822 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C823 1-126-964-11 ELECT 10uF 20.00% 50V
C826 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C830 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
* CN806 1-568-943-11 PIN, CONNECTOR 5P
< DIODE >
D806 8-719-404-50 DIODE MA111-TX
D807 8-719-404-50 DIODE MA111-TX
D808 8-719-404-50 DIODE MA111-TX
D809 8-719-404-50 DIODE MA111-TX
D810 8-719-069-56 DIODE UDZSTE-176.2B
< COIL >
L801 1-412-959-11 INDUCTOR 47uH
< TRANSISTOR >
Q803 8-729-808-42 TRANSISTOR 2SD1624-T-TD
Q804 8-729-808-42 TRANSISTOR 2SD1624-T-TD
< RESISTOR >
R850 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R855 1-216-809-11 METAL CHIP 100 5% 1/16W
R874 1-216-839-11 METAL CHIP 33K 5% 1/16W
< TRANSFORMER >
T801 1-437-416-11 TRANSFORMER, DC-DC CONVERTER
**************************************************************
A-4676-750-A DS 1179 BOARD, COMPLETE
************************
4-237-280-01 CAP, LED
< CONNECTOR >
* CN811 1-568-950-11 PIN, CONNECTOR 12P
< DIODE >
D801 8-719-057-29 DIODE SML78423C-TP15 (DISC 1)
D802 8-719-057-29 DIODE SML78423C-TP15 (DISC 2)
D803 8-719-057-29 DIODE SML78423C-TP15 (DISC 3)
D804 8-719-057-29 DIODE SML78423C-TP15 (DISC 4)
D805 8-719-057-29 DIODE SML78423C-TP15 (DISC 5)
< RESISTOR >
R816 1-216-813-11 METAL CHIP 220 5% 1/16W
R817 1-216-813-11 METAL CHIP 220 5% 1/16W
R818 1-216-813-11 METAL CHIP 220 5% 1/16W
R819 1-216-813-11 METAL CHIP 220 5% 1/16W
R820 1-216-813-11 METAL CHIP 220 5% 1/16W
R821 1-216-813-11 METAL CHIP 220 5% 1/16W
R822 1-216-813-11 METAL CHIP 220 5% 1/16W
R823 1-216-813-11 METAL CHIP 220 5% 1/16W
R824 1-216-813-11 METAL CHIP 220 5% 1/16W
R825 1-216-813-11 METAL CHIP 220 5% 1/16W
R826 1-216-839-11 METAL CHIP 33K 5% 1/16W
R827 1-216-833-11 METAL CHIP 10K 5% 1/16W
R828 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R829 1-216-821-11 METAL CHIP 1K 5% 1/16W
R830 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R831 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R832 1-216-819-11 METAL CHIP 680 5% 1/16W
R833 1-216-817-11 METAL CHIP 470 5% 1/16W
R834 1-216-815-11 METAL CHIP 330 5% 1/16W
R835 1-216-813-11 METAL CHIP 220 5% 1/16W
< SWITCH >
S811 1-571-760-11 SWITCH, KEY BOARD (DISC 1)
S812 1-571-760-11 SWITCH, KEY BOARD (eject)
S813 1-571-760-11 SWITCH, KEY BOARD (DISC 2)
S814 1-571-760-11 SWITCH, KEY BOARD (eject)
S815 1-571-760-11 SWITCH, KEY BOARD (DISC 3)
S816 1-571-760-11 SWITCH, KEY BOARD (eject)
S817 1-571-760-11 SWITCH, KEY BOARD (DISC 4)
S818 1-571-760-11 SWITCH, KEY BOARD (eject)
S819 1-571-760-11 SWITCH, KEY BOARD (DISC 5)
S820 1-571-760-11 SWITCH, KEY BOARD (eject)
**************************************************************
CONNECTOR DDCON 1179 DS 1179COMPONENT
