Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
136
HCD-C770/C990
S816 1-771-884-11 SWITCH, TACTILE (WITH LED) (A (DISC3))
S817 1-771-884-11 SWITCH, TACTILE (WITH LED) (DISC4)
S818 1-771-884-11 SWITCH, TACTILE (WITH LED) (A (DISC4))
S819 1-771-884-11 SWITCH, TACTILE (WITH LED) (DISC5)
S820 1-771-884-11 SWITCH, TACTILE (WITH LED) (A (DISC5))
**************************************************************
MODE MOTOR BOARD
*******************
**************************************************************
A-4729-053-A POWER BOARD, COMPLETE (C990)
A-4730-639-A POWER BOARD, COMPLETE (AEP, AUS)
A-4676-957-A POWER BOARD, COMPLETE (C770: US, CND)
***********************
1-533-313-11 HOLDER, FUSE
7-685-548-14 SCREW +BTP 3X12 TYPE2 N-S
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
0 C901 1-126-163-11 ELECT 4.7uF 20% 50V
0 C902 1-104-705-11 MYLAR 0.1uF 20% 250V
0 C903 1-104-705-11 MYLAR 0.1uF 20% 250V
0 C904 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
0 C905 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
0 C909 1-113-920-11 CERAMIC 0.0022uF 20% 250V
0 C910 1-113-920-11 CERAMIC 0.0022uF 20% 250V
0 C911 1-113-920-11 CERAMIC 0.0022uF 20% 250V
0 C912 1-100-192-11 ELECT 1000uF 20% 200V
(US, CND)
0 C912 1-165-911-21 ELECT 390uF 20% 450V
(AEP, AUS)
0 C913 1-136-203-11 FILM 10000PF 5% 630V
0 C914 1-126-967-11 ELECT 47uF 20% 50V
C915 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
0 C916 1-117-824-11 FILM 2200PF 3% 1.5KV
(US, CND)
0 C916 1-104-332-11 FILM 470PF 10% 2KV
(AEP, AUS)
C917 1-113-907-51 CERAMIC 0.0022uF 20% 250V
C918 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
0 C919 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(US, CND)
0 C919 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, AUS)
C920 1-137-699-11 FILM 2700PF 5% 630V
(US, CND)
C920 1-117-454-11 FILM 4700PF 5% 630V
(AEP, AUS)
C921 1-115-819-11 ELECT 2200uF 20% 35V
C922 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C923 1-115-819-11 ELECT 2200uF 20% 35V
C924 1-126-953-11 ELECT 2200uF 20% 35V
C925 1-126-947-11 ELECT 47uF 20% 16V
C926 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C927 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C928 1-126-953-11 ELECT 2200uF 20% 35V
C929 1-124-584-00 ELECT 100uF 20% 10V
C930 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C931 1-165-723-21 ELECT 1000uF
C932 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C933 1-165-723-21 ELECT 1000uF
C934 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C935 1-128-950-21 ELECT 1000uF 16V
C936 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C937 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
0 C938 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
0 C939 1-113-907-51 CERAMIC 0.0022uF 20% 250V
(AEP, AUS)
C941 1-126-947-11 ELECT 47uF 20% 16V
C942 1-126-963-11 ELECT 4.7uF 20% 50V
C946 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
CN902 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN903 1-506-996-11 PIN, CONNECTOR (PC BOARD) 14P
CN904 1-565-731-11 PLUG, CONNECTOR (2.5mm) 5P
< DIODE >
0 D902 8-719-022-92 DIODE RBV-604 (US, CND)
0 D902 8-719-312-05 DIODE RBV-606 (AEP, AUS)
D904 8-719-109-97 DIODE MTZJ-T-77-6.8B
0 D905 8-719-200-91 DIODE 11EQS10-TA1
0 D906 8-719-200-91 DIODE 11EQS10-TA1
0 D907 8-719-200-91 DIODE 11EQS10-TA1
0 D908 6-500-241-01 DIODE SARS03
D911 8-719-313-14 DIODE FML-22S
D912 8-719-109-93 DIODE RD6.2ESB2
D913 8-719-404-50 DIODE MA111-TX
D914 8-719-312-08 DIODE FMB-G16L
D915 8-719-200-82 DIODE 11ES2
D916 8-719-312-08 DIODE FMB-G16L
D917 8-719-200-82 DIODE 11ES2-NTA1B
0 D919 8-719-084-21 DIODE 10E6N-TA1B2
0 D920 8-719-084-21 DIODE 10E6N-TA1B2
D921 8-719-210-21 DIODE 11EQS04-TA1B
0 D931 8-719-110-53 DIODE MTZJ-T-77-20B
0 D932 8-719-924-13 DIODE MTZJ-T-77-22B
0 D933 8-719-200-91 DIODE 11EQS10-TA1
D990 8-719-404-50 DIODE MA111-TX
< GROUND TERMINAL >
EB901 1-537-770-21 TERMINAL BOARD, GROUND
EB902 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
0 IC901 6-702-338-01 IC STR-F6238 (US, CND)
0 IC901 6-702-385-01 IC STR-F6267S (AEP, AUS)
IC902 6-700-388-01 IC SE-B2
IC903 8-759-474-09 IC SI-8050S-LF1101
IC904 8-759-332-29 IC M51945BL
IC905 8-759-450-47 IC BA05T
IC906 6-700-813-01 IC SI-8033JF
IC908 6-701-021-01 IC SI-8120JF
IC909 8-759-510-71 IC BA10358F-E2 (US, CND)
IC909 8-759-970-89 IC BA10358F-T1 (AEP, AUS)
KEY MODE MOTOR POWER
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
To Next Page
