Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
137
HCD-C770/C990
< COIL >
L901 1-424-860-11 INDUCTOR 10uH
L902 1-456-183-11 INDUCTOR 150uH
L903 1-456-182-11 INDUCTOR 100uH
L904 1-414-398-11 INDUCTOR 10uH
L905 1-414-398-11 INDUCTOR 10uH
L906 1-414-398-11 INDUCTOR 10uH
L907 1-414-398-11 INDUCTOR 10uH
L908 1-414-398-11 INDUCTOR 10uH
L909 1-419-253-11 INDUCTOR 100uH
L910 1-414-398-11 INDUCTOR 10uH
L911 1-414-398-11 INDUCTOR 10uH
< LINE FILTER >
0 LF901 1-456-081-11 FILTER, LINE (AEP, AUS)
0 LF901 1-456-082-11 FILTER, LINE (US, CND)
0 LF902 1-456-081-11 FILTER, LINE (AEP, AUS)
0 LF902 1-456-082-11 FILTER, LINE (US, CND)
< IC >
0 PC901 8-749-019-04 IC TLP421
< TRANSISTOR >
Q901 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q902 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q903 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q904 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
0 Q905 8-729-111-29 TRANSISTOR 2SD1616A-TP-LK
Q906 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q910 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q911 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q912 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q914 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q990 8-729-026-67 TRANSISTOR 2SB1640 (TP)
Q991 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q992 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
< RESISTOR >
0 R900 1-219-237-11 SOLID 3.3M 20% 1/2W
(US, CND)
0 R901 1-216-813-11 METAL CHIP 220 5% 1/10W
0 R902 1-245-392-51 METAL OXIDE 0.15 5% 1W
(US, CND)
0 R903 1-245-392-51 METAL OXIDE 0.15 5% 1W
0 R904 1-216-341-11 METAL OXIDE 0.22 5% 1W
0 R905 1-215-926-00 METAL OXIDE 33K 5% 3W
(US, CND)
0 R905 1-215-928-11 METAL OXIDE 68K 5% 3W
(AEP, AUS)
R906 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R907 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
0 R908 1-215-928-11 METAL OXIDE 68K 5% 3W
(AEP, AUS)
0 R909 1-215-902-11 METAL OXIDE 47K 5% 2W
R910 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
0 R911 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
0 R912 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
0 R913 1-249-385-11 CARBON 2.2 5% 1/6W
R914 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R915 1-216-812-11 METAL CHIP 180 5% 1/10W
R916 1-216-820-11 METAL CHIP 820 5% 1/10W
(AEP, AUS)
R916 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
(US, CND)
R917 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R918 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R919 1-216-835-11 METAL CHIP 15K 5% 1/10W
R920 1-216-809-11 METAL CHIP 100 5% 1/10W
R921 1-216-837-11 METAL CHIP 22K 5% 1/10W
R922 1-218-866-11 METAL CHIP 6.2K 0.5% 1/10W
R923 1-216-833-11 METAL CHIP 10K 5% 1/10W
R924 1-216-818-11 METAL CHIP 560 5% 1/10W
R925 1-216-812-11 METAL CHIP 180 5% 1/10W
R926 1-216-845-11 METAL CHIP 100K 5% 1/10W
R927 1-216-821-11 METAL CHIP 1K 5% 1/10W
R928 1-216-833-11 METAL CHIP 10K 5% 1/10W
R929 1-216-797-11 METAL CHIP 10 5% 1/10W
0R930 1-219-237-11 SOLID 3.3M 20% 1/2W
(AEP, AUS)
R931 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R932 1-216-833-11 METAL CHIP 10K 5% 1/10W
R933 1-216-833-11 METAL CHIP 10K 5% 1/10W
0R934 1-215-904-11 METAL OXIDE 100K 5% 2W
(AEP, AUS)
R935 1-216-845-11 METAL CHIP 100K 5% 1/10W
R936 1-216-847-11 METAL CHIP 150K 5% 1/10W
R937 1-216-821-11 METAL CHIP 1K 5% 1/10W
R938 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R939 1-216-049-11 METAL CHIP 1K 5% 1/10W
R940 1-216-077-00 METAL CHIP 15K 5% 1/10W
R941 1-216-833-11 METAL CHIP 10K 5% 1/10W
R942 1-216-049-11 METAL CHIP 1K 5% 1/10W
R943 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
< TRANSFORMER >
0T901 1-437-865-11 TRANSFORMER, POWER (US, CND)
0T901 1-437-866-11 TRANSFORMER, POWER (AEP, AUS)
< THERMISTOR >
0TH901 1-803-916-11 THERMISTOR, NTC
**************************************************************
POWER LED BOARD
*****************
< LED >
D812 8-719-074-42 LED SLR325VR-T31 (STANDBY)
< RESISTOR >
R804 1-216-817-11 METAL CHIP 470 5% 1/10W
**************************************************************
POWER POWER LED
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
