Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
139
HCD-C770/C990
C049 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN001 1-815-031-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN002 1-784-836-21 CONNECTOR, FFC (LIF (NON-ZIF)) 29P
CN003 1-784-861-21 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< DIODE >
D001 8-719-988-61 DIODE 1SS355TE-17
D002 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC001 8-752-417-53 IC CXD1881AR
< COIL >
L001 1-412-031-11 INDUCTOR CHIP 47uH
L002 1-412-031-11 INDUCTOR CHIP 47uH
< TRANSISTOR >
Q001 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
Q002 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
< RESISTOR >
R001 1-218-668-11 METAL CHIP 100 0.5% 1/16W
R003 1-216-803-11 METAL CHIP 33 5% 1/10W
R004 1-216-803-11 METAL CHIP 33 5% 1/10W
R005 1-216-841-11 METAL CHIP 47K 5% 1/10W
R006 1-216-817-11 METAL CHIP 470 5% 1/10W
R007 1-216-803-11 METAL CHIP 33 5% 1/10W
R008 1-216-803-11 METAL CHIP 33 5% 1/10W
R009 1-216-841-11 METAL CHIP 47K 5% 1/10W
R010 1-216-817-11 METAL CHIP 470 5% 1/10W
R011 1-216-864-11 METAL CHIP 0 5% 1/10W
R012 1-216-864-11 METAL CHIP 0 5% 1/10W
R013 1-216-864-11 METAL CHIP 0 5% 1/10W
R014 1-216-864-11 METAL CHIP 0 5% 1/10W
R015 1-216-864-11 METAL CHIP 0 5% 1/10W
R016 1-216-864-11 METAL CHIP 0 5% 1/10W
R017 1-216-864-11 METAL CHIP 0 5% 1/10W
R018 1-216-864-11 METAL CHIP 0 5% 1/10W
R019 1-216-864-11 METAL CHIP 0 5% 1/10W
R020 1-216-864-11 METAL CHIP 0 5% 1/10W
R021 1-216-864-11 METAL CHIP 0 5% 1/10W
R022 1-216-813-11 METAL CHIP 220 5% 1/10W
R023 1-216-820-11 METAL CHIP 820 5% 1/10W
R024 1-216-864-11 METAL CHIP 0 5% 1/10W
R025 1-216-809-11 METAL CHIP 100 5% 1/10W
R026 1-218-718-11 METAL CHIP 12K 0.5% 1/16W
R027 1-216-864-11 METAL CHIP 0 5% 1/10W
R028 1-216-864-11 METAL CHIP 0 5% 1/10W
R029 1-216-864-11 METAL CHIP 0 5% 1/10W
R032 1-216-809-11 METAL CHIP 100 5% 1/10W
R033 1-216-864-11 METAL CHIP 0 5% 1/10W
R034 1-219-570-11 RES-CHIP 10M 5% 1/10W
R035 1-216-864-11 METAL CHIP 0 5% 1/10W
R041 1-216-821-11 METAL CHIP 1K 5% 1/10W
**************************************************************
ROLLER MOTOR BOARD
********************
**************************************************************
SEL BOARD
**********
S826 1-771-692-11 SWITCH, SLIDE (SCAN SELECT)
**************************************************************
1-685-004-11 SENSOR BOARD
**************
< PHOTO SENSOR >
IC751 8-749-017-45 SENSOR, PHOTO RPR-220C1N
(DISC INSERT DETECT SENSOR)
**************************************************************
1-685-006-11 STOCKER MOTOR BOARD
*********************
**************************************************************
1-685-008-11 SW (1) BOARD
************
< SWITCH >
S711 1-786-382-11 SWITCH, PUSH (1 KEY)
(DISC INSERT (8/12cm))
**************************************************************
1-685-009-11 SW (2) BOARD
************
< SWITCH >
S713 1-786-382-11 SWITCH, PUSH (1 KEY) (DISC IN (8/12cm))
S714 1-786-382-11 SWITCH, PUSH (1 KEY) (DISC IN (8cm))
**************************************************************
1-685-010-11 SW (3) BOARD
************
< SWITCH >
S715 1-786-382-11 SWITCH, PUSH (1 KEY) (DISC OUT)
**************************************************************
1-685-011-11 SW (4) BOARD
************
< SWITCH >
S716 1-786-382-11 SWITCH, PUSH (1 KEY) (STOCKER IN/OUT)
S717 1-786-382-11 SWITCH, PUSH (1 KEY) (DISC POSITION)
S718 1-786-382-11 SWITCH, PUSH (1 KEY) (STOCKING)
**************************************************************
RF ROLLER MOTOR SEL SENSOR
STOCKER MOTOR SW (1) SW (2) SW (3) SW (4)
