Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
140
HCD-C770/C990
A-4728-874-A VIDEO BOARD, COMPLETE
**********************
< CAPACITOR >
C202 1-126-369-11 ELECT 220uF 20% 6.3V
C218 1-124-589-11 ELECT 47uF 20% 16V
C248 1-126-153-11 ELECT 22uF 20% 6.3V
C252 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C265 1-126-157-11 ELECT 10uF 20% 16V
C267 1-124-584-00 ELECT 100uF 20% 10V
C272 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C274 1-126-157-11 ELECT 10uF 20% 16V
C275 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C276 1-126-157-11 ELECT 10uF 20% 16V
C277 1-126-153-11 ELECT 22uF 20% 6.3V
C278 1-126-157-11 ELECT 10uF 20% 16V
C279 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C280 1-126-160-11 ELECT 1uF 20% 50V
C281 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C282 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C283 1-126-160-11 ELECT 1uF 20% 50V
C284 1-124-584-00 ELECT 100uF 20% 10V
C285 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C286 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C287 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C288 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C289 1-126-157-11 ELECT 10uF 20% 16V
C290 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C291 1-126-157-11 ELECT 10uF 20% 16V
C292 1-126-369-11 ELECT 220uF 20% 6.3V
C293 1-124-584-11 ELECT 100uF 20% 10V
C294 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C295 1-124-584-00 ELECT 100uF 20% 10V
C296 1-126-518-11 ELECT 470uF 20% 4V
C297 1-126-369-11 ELECT 220uF 20% 6.3V
C298 1-124-584-11 ELECT 100uF 20% 10V
C299 1-126-153-11 ELECT 22uF 20% 6.3V
C300 1-124-584-00 ELECT 100uF 20% 10V
C301 1-126-153-11 ELECT 22uF 20% 6.3V
C302 1-124-584-00 ELECT 100uF 20% 10V
< CONNECTOR >
CN203 1-779-551-21 CONNECTOR, FFC (LIF (NON-ZIF)) 14P
CN207 1-779-548-21 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
< FERRITE BEAD >
FB201 1-469-324-21 FERRITE 0uH
FB202 1-469-324-21 FERRITE 0uH
FB203 1-469-324-21 FERRITE 0uH
FB204 1-469-324-21 FERRITE 0uH
FB205 1-469-324-21 FERRITE 0uH
FB206 1-469-324-21 FERRITE 0uH
< IC >
IC204 6-600-013-01 IC TORX179L (OPTICAL DIGITAL IN VIDEO2)
IC206 6-702-334-01 IC MM1510
IC207 8-759-696-10 IC NJM2235V (TE2)
VIDEO VOL
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
IC208 6-702-335-01 IC MM1568
IC209 8-759-284-49 IC NJM2285V-TE2
< TERMINAL BOARD >
J202 1-694-920-11 TERMINAL BOARD (MONITOR OUT)
< COIL >
L202 1-469-525-11 INDUCTOR 10uH
L207 1-469-525-11 INDUCTOR 10uH
L209 1-469-525-11 INDUCTOR 10uH
< TRANSISTOR >
Q210 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q214 1-801-806-11 TRANSISTOR DTC144EKA-T146
< RESISTOR >
R256 1-216-833-11 METAL CHIP 10K 5% 1/10W
R259 1-218-285-11 RES-CHIP 75 5% 1/10W
R265 1-216-833-11 METAL CHIP 10K 5% 1/10W
R266 1-216-833-11 METAL CHIP 10K 5% 1/10W
R267 1-218-285-11 RES-CHIP 75 5% 1/10W
R268 1-218-285-11 RES-CHIP 75 5% 1/10W
R269 1-218-285-11 RES-CHIP 75 5% 1/10W
R270 1-218-285-11 RES-CHIP 75 5% 1/10W
R273 1-218-285-11 RES-CHIP 75 5% 1/10W
R278 1-216-833-11 METAL CHIP 10K 5% 1/10W
R286 1-216-833-11 METAL CHIP 10K 5% 1/10W
**************************************************************
1-685-887-11 VOL BOARD
**********
< CAPACITOR >
C800 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C801 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
* CN820 1-568-941-11 PIN, CONNECTOR 3P
< SWITCH >
S800 1-418-632-11 ENCODER, ROTARY (VOLUME)
**************************************************************
MISCELLANEOUS
**************
104 1-824-479-11 FLEXIBLE FLAT CABLE (10 CORE)
110 1-824-478-11 FLEXIBLE FLAT CABLE (12 CORE)
201 1-824-626-11 FLEXIBLE FLAT CABLE (19 CORE)
202 1-824-483-11 FLEXIBLE FLAT CABLE (28 CORE)
204 1-824-478-11 FLEXIBLE FLAT CABLE (12 CORE)
205 1-824-625-11 FLEXIBLE FLAT CABLE (17 CORE)
206 1-500-657-11 CORE, FERRITE
207 1-824-480-11 FLEXIBLE FLAT CABLE (29 CORE)
208 1-824-481-11 FLEXIBLE FLAT CABLE (14 CORE)
209 1-824-482-11 FLEXIBLE FLAT CABLE (29 CORE)
212 1-469-854-11 CORE FERRITE
252 1-824-485-11 FLEXIBLE FLAT CABLE (11 CORE)
