Sony HCD-C770 - Page 98

98
HCD-C770/C990
Pin No. Pin Name I/O Description
167 XTAL I
33.8688 MHz clock signal input terminal
168 VSS —
Ground terminal (digital system)
169 XTA2 O
System clock output terminal (33.8688 MHz)
170 XTA1 I
System clock input terminal (33.8688 MHz)
171 VDD —
Power supply terminal (+3.3V) (digital system)
172 to 17
6
D0 to D4 I/O
Two-way data bus with the mechanism controller
