Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
55
HCD-CL1/CL3
BACK LIGHT
BD (CD)
R884 1-249-429-11 CARBON 10K 5% 1/4W
R885 1-249-441-11 CARBON 100K 5% 1/4W
R891 1-249-429-11 CARBON 10K 5% 1/4W
R892 1-249-441-11 CARBON 100K 5% 1/4W
R893 1-247-903-00 CARBON 1M 5% 1/4W
R898 1-249-441-11 CARBON 100K 5% 1/4W
(CL3)
R899 1-249-429-11 CARBON 10K 5% 1/4W
(CL3)
R951 1-249-425-11 CARBON 4.7K 5% 1/4W F
R952 1-249-425-11 CARBON 4.7K 5% 1/4W F
R961 1-249-437-11 CARBON 47K 5% 1/4W
(CL1:E,MX/CL3:MX)
R962 1-249-437-11 CARBON 47K 5% 1/4W
(CL1:E,MX/CL3:MX)
0R971 1-212-881-11 FUSIBLE 100 5% 1/4W
0R972 1-212-881-11 FUSIBLE 100 5% 1/4W
R973 1-249-435-11 CARBON 33K 5% 1/4W
R974 1-249-433-11 CARBON 22K 5% 1/4W
R975 1-249-437-11 CARBON 47K 5% 1/4W
R976 1-249-441-11 CARBON 100K 5% 1/4W
R977 1-249-421-11 CARBON 2.2K 5% 1/4W F
R978 1-249-433-11 CARBON 22K 5% 1/4W
R979 1-249-421-11 CARBON 2.2K 5% 1/4W F
R980 1-249-429-11 CARBON 10K 5% 1/4W
R981 1-249-429-11 CARBON 10K 5% 1/4W
0R982 1-202-972-61 FUSIBLE 1 5% 1/4W
< RELAY >
RY801 1-515-920-11 RELAY (24V)
< TERMINAL >
TM801 1-694-677-12 TERMINAL BOARD (4P)
************************************************************
1-679-981-11 BACK LIGHT BOARD
****************
< CAPACITOR >
C709 1-104-665-11 ELECT 100uF 20% 10V
C777 1-162-294-31 CERAMIC 0.001uF 10% 50V
(CL1:US/CL3)
C778 1-162-294-31 CERAMIC 0.001uF 10% 50V
(CL1:US/CL3)
C779 1-162-294-31 CERAMIC 0.001uF 10% 50V
(CL1:US/CL3)
< CONNECTOR >
CN771 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D771 8-719-075-50 DIODE SELS6B14C-TP6(BACK LIGHT)(CL1)
D772 8-719-075-50 DIODE SELS6B14C-TP6(BACK LIGHT)(CL1)
D773 8-719-075-50 DIODE SELS6B14C-TP6(BACK LIGHT)(CL1)
D774 8-719-075-50 DIODE SELS6B14C-TP6(BACK LIGHT)(CL1)
D775 8-719-075-50 DIODE SELS6B14C-TP6(BACK LIGHT)(CL1)
D776 8-719-075-50 DIODE SELS6B14C-TP6(BACK LIGHT)(CL1)
D777 8-719-082-32 DIODE SELU2E10CTP6(BACK LIGHT)
(CL1:US/CL3)
D778 8-719-082-32 DIODE SELU2E10CTP6(BACK LIGHT)
(CL1:US/CL3)
D779 8-719-082-32 DIODE SELU2E10CTP6(BACK LIGHT)
(CL1:US/CL3)
< RESISTOR >
R771 1-249-409-11 CARBON 220 5% 1/4W F
(CL1)
R771 1-249-406-11 CARBON 120 5% 1/4W F
(CL3)
R772 1-249-409-11 CARBON 220 5% 1/4W F
(CL1)
R772 1-249-406-11 CARBON 120 5% 1/4W F
(CL3)
R773 1-249-409-11 CARBON 220 5% 1/4W F
(CL1)
R773 1-249-406-11 CARBON 120 5% 1/4W F
(CL3)
************************************************************
A-4725-531-A BD (CD) BOARD, COMPLETE
***********************
< CAPACITOR >
C101 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C103 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C104 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C108 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C109 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C110 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C111 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C112 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C114 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C116 1-104-665-11 ELECT 100uF 20% 10V
C117 1-104-665-11 ELECT 100uF 20% 10V
C118 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C121 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C122 1-124-584-00 ELECT 100uF 20% 10V
C123 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C124 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C125 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C126 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C127 1-124-584-00 ELECT 100uF 20% 10V
C129 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C130 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C131 1-104-665-11 ELECT 100uF 20% 10V
C133 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C143 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C145 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C153 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C159 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C162 1-104-665-11 ELECT 100uF 20% 10V
C165 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C167 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C168 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C171 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C172 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C181 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C182 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C183 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C184 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C185 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C190 1-115-156-11 CERAMIC CHIP 1uF 10V
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
