Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
56
HCD-CL1/CL3
BD (CD)
C191 1-124-584-00 ELECT 100uF 20% 10V
C192 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C193 1-104-665-11 ELECT 100uF 20% 10V
C194 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C195 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C196 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C197 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C198 1-124-584-00 ELECT 100uF 20% 10V
< CONNECTOR >
CN101 1-568-864-11 CONNECTOR, FFC 21P
CN102 1-793-907-11 CONNECTOR, FFC/FPC 16P
< DIODE >
D101 8-719-422-12 DIODE UDZ-TE-17-3.9B
< FERRITE BEAD >
FB101 1-500-445-11 FERRITE 0UH
FB102 1-500-445-11 FERRITE 0UH
< IC >
IC101 8-752-402-31 IC CXD3017Q
IC102 8-759-827-41 IC BA5974FM-E2
IC103 8-752-089-74 IC CXA2581N-T4
< JUMPER RESISTOR >
JR101 1-216-295-11 SHORT 0
JR102 1-216-295-11 SHORT 0
JR103 1-216-295-11 SHORT 0
JR104 1-216-295-11 SHORT 0
JR105 1-216-295-11 SHORT 0
JR106 1-216-295-11 SHORT 0
JR122 1-216-296-11 SHORT 0
JR123 1-216-296-11 SHORT 0
JR124 1-216-296-11 SHORT 0
JR125 1-216-296-11 SHORT 0
< COIL >
L101 1-469-553-21 INDUCTOR 4.7uH
< TRANSISTOR >
Q101 8-729-010-08 TRANSISTOR MSB710-RT1
Q102 8-729-920-85 TRANSISTOR 2SD1664-T100-QR
< RESISTOR >
R101 1-216-049-11 RES-CHIP 1K 5% 1/10W
R102 1-216-097-11 RES-CHIP 100K 5% 1/10W
R103 1-216-077-91 RES-CHIP 15K 5% 1/10W
R104 1-216-085-00 METAL CHIP 33K 5% 1/10W
R105 1-216-049-11 RES-CHIP 1K 5% 1/10W
R106 1-216-049-11 RES-CHIP 1K 5% 1/10W
R107 1-216-073-00 METAL CHIP 10K 5% 1/10W
R108 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R109 1-216-121-11 RES-CHIP 1M 5% 1/10W
R111 1-216-099-00 METAL CHIP 120K 5% 1/10W
R114 1-218-745-11 RES-CHIP 160K 5% 1/16W
R116 1-216-001-00 METAL CHIP 10 5% 1/10W
R117 1-216-049-11 RES-CHIP 1K 5% 1/10W
R118 1-216-025-11 RES-CHIP 100 5% 1/10W
R119 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R120 1-216-077-91 RES-CHIP 15K 5% 1/10W
R122 1-216-097-11 RES-CHIP 100K 5% 1/10W
R123 1-216-073-00 METAL CHIP 10K 5% 1/10W
R124 1-216-097-11 RES-CHIP 100K 5% 1/10W
R131 1-216-033-00 METAL CHIP 220 5% 1/10W
R143 1-216-085-00 METAL CHIP 33K 5% 1/10W
R144 1-216-085-00 METAL CHIP 33K 5% 1/10W
R147 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R148 1-216-001-00 METAL CHIP 10 5% 1/10W
R149 1-216-001-00 METAL CHIP 10 5% 1/10W
R158 1-216-083-00 METAL CHIP 27K 5% 1/10W
R159 1-216-083-00 METAL CHIP 27K 5% 1/10W
R162 1-216-097-11 RES-CHIP 100K 5% 1/10W
R171 1-216-081-00 METAL CHIP 22K 5% 1/10W
R172 1-216-081-00 METAL CHIP 22K 5% 1/10W
R173 1-216-081-00 METAL CHIP 22K 5% 1/10W
R181 1-216-081-00 METAL CHIP 22K 5% 1/10W
R182 1-216-081-00 METAL CHIP 22K 5% 1/10W
R183 1-216-081-00 METAL CHIP 22K 5% 1/10W
R190 1-216-033-00 METAL CHIP 220 5% 1/10W
R191 1-216-085-00 METAL CHIP 33K 5% 1/10W
R192 1-216-085-00 METAL CHIP 33K 5% 1/10W
R193 1-216-099-00 METAL CHIP 120K 5% 1/10W
R194 1-216-097-11 RES-CHIP 100K 5% 1/10W
R195 1-216-113-00 METAL CHIP 470K 5% 1/10W
R196 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R198 1-216-295-11 SHORT 0
< CHIP NETWORK >
RN101 1-233-576-11 RES, CHIP NETWORK 100
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL
************************************************************
1-678-463-11 DISK SENSOR BOARD
******************
< IC >
IC751 8-749-924-30 PHOTO REFLECTOR GP2S28
< RESISTOR >
R751 1-249-407-11 CARBON 150 5% 1/4W F
************************************************************
1-678-460-11 DRIVER BOARD
*************
< CAPACITOR >
C701 1-124-261-00 ELECT 10uF 20% 50V
C705 1-124-261-00 ELECT 10uF 20% 50V
C706 1-164-159-11 CERAMIC 0.1uF 50V
C707 1-164-159-11 CERAMIC 0.1uF 50V
DISK SENSOR DRIVER
