Sony HCD-DR3 - Page 41

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
41
R94 1-249-417-11 CARBON 1K 5% 1/4W F
R95 1-249-417-11 CARBON 1K 5% 1/4W F
R96 1-249-417-11 CARBON 1K 5% 1/4W F
R97 1-249-417-11 CARBON 1K 5% 1/4W F
R98 1-249-417-11 CARBON 1K 5% 1/4W F
R77L 1-247-855-11 CARBON 10K 5% 1/4W
R77R 1-247-855-11 CARBON 10K 5% 1/4W
R78L 1-247-855-11 CARBON 10K 5% 1/4W
R78R 1-247-855-11 CARBON 10K 5% 1/4W
R79L 1-247-855-11 CARBON 10K 5% 1/4W
R79R 1-247-855-11 CARBON 10K 5% 1/4W
R80L 1-247-855-11 CARBON 10K 5% 1/4W
R80R 1-247-855-11 CARBON 10K 5% 1/4W
< VIBRATOR >
XTL01 1-567-908-11 VIBRATOR, CRYSTAL 16.9344MHz
************************************************************
1-674-634-11 CD KEY BOARD
************
< RESISTOR >
R651 1-249-431-11 CARBON 15K 5% 1/4W
R652 1-247-835-11 CARBON 1.5K 5% 1/4W
R658 1-247-839-11 CARBON 2.2K 5% 1/4W
R659 1-247-843-11 CARBON 3.3K 5% 1/4W
R660 1-247-847-11 CARBON 4.7K 5% 1/4W
R661 1-249-428-11 CARBON 8.2K 5% 1/4W F
R662 1-249-418-11 CARBON 1.2K 5% 1/4W F
< SWITCH >
S639 1-762-875-11 SWITCH, KEYBOARD (DISC 1)
S640 1-762-875-11 SWITCH, KEYBOARD (DISC 2)
S641 1-762-875-11 SWITCH, KEYBOARD (DISC 3)
S642 1-762-875-11 SWITCH, KEYBOARD (DISC 4)
S643 1-762-875-11 SWITCH, KEYBOARD (DISC 5)
S644 1-762-875-11 SWITCH, KEYBOARD (EDIT)
************************************************************
1-675-421-11 CD SENSOR BOARD
****************
< RESISTOR >
R47 1-249-416-11 CARBON 820 5% 1/4W F
< SENSOR >
SENS01 8-749-924-18 PHOTO INTERRUPTER RPI-1391
************************************************************
1-674-632-11 CD SW BOARD
************
< SWITCH >
S653 1-771-169-11 SWITCH (DOOR)
************************************************************
1-675-424-11 CONNECTOR BOARD
****************
< CONNECTOR >
* CN11 1-770-334-11 PIN, CONNECTOR (PC BOARD) 17P
************************************************************
1-675-423-11 DISC NO BOARD
*************
< RESISTOR >
R04 1-247-862-11 CARBON 20K 5% 1/4W
************************************************************
A-4426-395-A FRONT BOARD, COMPLETE (XB200)
**********************
A-4426-396-A FRONT BOARD, COMPLETE (DR3:E)
**********************
A-4426-397-A FRONT BOARD, COMPLETE (DR3:AUS)
**********************
A-4426-398-A FRONT BOARD, COMPLETE (DR3:AR)
**********************
A-4426-399-A FRONT BOARD, COMPLETE (DR3:SP)
**********************
A-4426-400-A FRONT BOARD, COMPLETE (DR3:MX/DR330)
**********************
< CAPACITOR >
C601 1-126-960-11 ELECT 1uF 20% 50V
C602 1-126-933-11 ELECT 100uF 20% 16V
C603 1-126-916-11 ELECT 1000uF 20% 6.3V
(DR3:MX,AR,AUS/DR330/XB200)
C604 1-161-494-00 CERAMIC 0.022uF 25V
C605 1-104-664-11 ELECT 47uF 20% 10V
C606 1-164-159-11 CERAMIC 0.1uF 50V
C608 1-126-958-11 ELECT 0.33uF 20% 50V
C609 1-164-159-11 CERAMIC 0.1uF 50V
C610 1-126-964-11 ELECT 10uF 20% 50V
C611 1-161-494-00 CERAMIC 0.022uF 25V
C612 1-162-286-31 CERAMIC 220PF 10% 50V
C613 1-102-962-00 CERAMIC 30PF 5% 50V
C614 1-102-962-00 CERAMIC 30PF 5% 50V
C615 1-162-286-31 CERAMIC 220PF 10% 50V
C616 1-164-159-11 CERAMIC 0.1uF 50V
C618 1-162-286-31 CERAMIC 220PF 10% 50V
C619 1-162-286-31 CERAMIC 220PF 10% 50V
C620 1-162-286-31 CERAMIC 220PF 10% 50V
C621 1-162-282-31 CERAMIC 100PF 10% 50V
C622 1-162-286-31 CERAMIC 220PF 10% 50V
C623 1-162-286-31 CERAMIC 220PF 10% 50V
C624 1-162-286-31 CERAMIC 220PF 10% 50V
C625 1-126-964-11 ELECT 10uF 20% 50V
C626 1-161-494-00 CERAMIC 0.022uF 25V
C627 1-162-286-31 CERAMIC 220PF 10% 50V
C628 1-162-286-31 CERAMIC 220PF 10% 50V
C629 1-162-294-31 CERAMIC 0.001uF 10% 50V
C630 1-162-294-31 CERAMIC 0.001uF 10% 50V
C631 1-126-964-11 ELECT 10uF 20% 50V
C632 1-161-494-00 CERAMIC 0.022uF 25V
C633 1-162-294-31 CERAMIC 0.001uF 10% 50V
C634 1-126-964-11 ELECT 10uF 20% 50V
C635 1-126-964-11 ELECT 10uF 20% 50V
C636 1-161-494-00 CERAMIC 0.022uF 25V
C637 1-162-294-31 CERAMIC 0.001uF 10% 50V
C638 1-162-294-31 CERAMIC 0.001uF 10% 50V
C639 1-162-294-31 CERAMIC 0.001uF 10% 50V
C640 1-104-664-11 ELECT 47uF 20% 10V
C643 1-126-959-11 ELECT 0.47uF 20% 50V
C644 1-164-206-41 CERAMIC 0.047uF 99% 50V
CD KEYCD DECORD CD SENSOR
CD SW CONNECTOR FRONTDISC NO
