Sony HCD-DR3 - Integrated Circuit (IC) Part Numbers

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
42
C645 1-126-957-11 ELECT 0.22uF 20% 50V
C646 1-126-957-11 ELECT 0.22uF 20% 50V
C647 1-162-306-11 CERAMIC 0.01uF 20% 16V
C648 1-126-957-11 ELECT 0.22uF 20% 50V
C649 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C650 1-137-352-11 FILM 0.033uF 5% 100V
C651 1-126-957-11 ELECT 0.22uF 20% 50V
C653 1-162-293-31 CERAMIC 820PF 10% 50V
C654 1-126-957-11 ELECT 0.22uF 20% 50V
C655 1-126-957-11 ELECT 0.22uF 20% 50V
C658 1-162-286-31 CERAMIC 220PF 10% 50V
C659 1-162-286-31 CERAMIC 220PF 10% 50V
C660 1-162-286-31 CERAMIC 220PF 10% 50V
C661 1-162-286-31 CERAMIC 220PF 10% 50V
C662 1-162-286-31 CERAMIC 220PF 10% 50V
C663 1-126-934-11 ELECT 220uF 20% 16V
C664 1-126-934-11 ELECT 220uF 20% 16V
C665 1-162-286-31 CERAMIC 220PF 10% 50V
C667 1-162-286-31 CERAMIC 220PF 10% 50V
C668 1-126-933-11 ELECT 100uF 20% 16V
C669 1-164-206-41 CERAMIC 0.047uF 99% 50V
C670 1-164-206-41 CERAMIC 0.047uF 99% 50V
C671 1-126-960-11 ELECT 1uF 20% 50V
C672 1-162-286-31 CERAMIC 220PF 10% 50V
C673 1-126-963-11 ELECT 4.7uF 20% 50V
< CONNECTOR >
* CN603 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
* CN606 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN607 1-568-835-21 SOCKET, CONNECTOR 16P
< DIODE >
D601 8-719-031-85 DIODE 1N4002L
D602 8-719-031-85 DIODE 1N4002L
D603 8-719-991-33 DIODE 1SS133T-77
D604 8-719-991-33 DIODE 1SS133T-77
D605 8-719-947-12 DIODE UZ-4.7BSA
D607 8-719-991-33 DIODE 1SS133T-77 (DR3:E,AUS/XB200)
D606 8-719-991-33 DIODE 1SS133T-77 (DR3:MX/DR330)
D608 8-719-991-33 DIODE 1SS133T-77 (DR3:MX/DR330)
D609 8-719-991-33 DIODE 1SS133T-77
(DR3:MX,AUS/DR330/XB200)
D611 8-719-991-33 DIODE 1SS133T-77 (DR3:AUS/XB200)
D612 8-719-991-33 DIODE 1SS133T-77 (DR3:SP)
D613 8-719-991-33 DIODE 1SS133T-77
D614 8-719-991-33 DIODE 1SS133T-77
D615 8-719-991-33 DIODE 1SS133T-77
D616 8-719-991-33 DIODE 1SS133T-77
D617 8-719-991-33 DIODE 1SS133T-77
D618 8-719-991-33 DIODE 1SS133T-77
D619 8-719-991-33 DIODE 1SS133T-77
D620 8-719-991-33 DIODE 1SS133T-77
D621 8-719-991-33 DIODE 1SS133T-77
D622 8-719-991-33 DIODE 1SS133T-77
D624 8-719-991-33 DIODE 1SS133T-77
D723 8-719-991-33 DIODE 1SS133T-77
D730 8-719-991-33 DIODE 1SS133T-77
D731 8-719-991-33 DIODE 1SS133T-77
< FLUORESCENTINDICATOR >
FLD601 1-517-840-31 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 8-759-595-06 IC LC866540A-5K40
IC602 8-759-275-23 IC BU2092
IC603 8-759-473-61 IC BU2114
IC604 8-759-000-49 IC TC4066BP
IC606 8-759-916-52 IC TC74HC165AP
IC607 8-759-234-75 IC TC74HC4094AP
< COIL >
L601 1-414-151-11 INDUCTOR 470uH
< LED >
LED601 8-719-062-09 LED SEL2815A-CD (ENTER/NEXT9
LED602 8-719-303-02 LED SEL2510C (TUNER/BAND)
LED603 8-719-028-38 LED SEL2215R-TP1 (GROOVE)
LED605 8-719-052-46 LED SEL1450EKM-TP5 (SALSA)
LED606 8-719-052-46 LED SEL1450EKM-TP5 (JAZZ)
LED607 8-719-052-46 LED SEL1450EKM-TP5 (POPS)
LED608 8-719-052-46 LED SEL1450EKM-TP5 (ROCK)
LED610 8-719-028-38 LED SEL2215R-TP1 (r REC)
LED611 8-719-062-09 LED SEL2815A-CD (P PAUSE)
LED612 8-719-303-02 LED SEL2510C (TAPE B, “)
LED613 8-719-303-02 LED SEL2510C (TAPE B, ”)
LED614 8-719-303-02 LED SEL2510C (TAPE A, “)
LED615 8-719-303-02 LED SEL2510C (TAPE A, ”)
< TRANSISTOR >
Q601 8-729-194-57 TRANSISTOR 2SC945TP-P
Q602 8-729-194-57 TRANSISTOR 2SC945TP-P
Q603 8-729-194-57 TRANSISTOR 2SC945TP-P
Q604 8-729-119-76 TRANSISTOR 2SA733-P
Q605 8-729-194-57 TRANSISTOR 2SC945TP-P (DR3:SP)
Q606 8-729-026-29 TRANSISTOR 2SJ346 (DR3:SP)
Q607 8-729-194-57 TRANSISTOR 2SC945TP-P
Q608 8-729-026-29 TRANSISTOR 2SJ346
Q609 8-729-026-29 TRANSISTOR 2SJ346
Q610 8-729-194-57 TRANSISTOR 2SC945TP-P
Q611 8-729-194-57 TRANSISTOR 2SC945TP-P
Q612 8-729-194-57 TRANSISTOR 2SC945TP-P
Q613 8-729-993-43 TRANSISTOR 2SA934R
Q614 8-729-993-43 TRANSISTOR 2SA934R
Q615 8-729-993-43 TRANSISTOR 2SA934R
< RESISTOR >
R601 1-247-871-11 CARBON 47K 5% 1/4W
R602 1-249-417-11 CARBON 1K 5% 1/4W F
R603 1-249-417-11 CARBON 1K 5% 1/4W F
R604 1-247-871-11 CARBON 47K 5% 1/4W
R605 1-247-871-11 CARBON 47K 5% 1/4W
R606 1-249-417-11 CARBON 1K 5% 1/4W F
R607 1-249-431-11 CARBON 15K 5% 1/4W
R608 1-247-871-11 CARBON 47K 5% 1/4W
R609 1-247-855-11 CARBON 10K 5% 1/4W
R610 1-247-855-11 CARBON 10K 5% 1/4W
R611 1-247-855-11 CARBON 10K 5% 1/4W
R612 1-247-855-11 CARBON 10K 5% 1/4W
R613 1-247-855-11 CARBON 10K 5% 1/4W
R614 1-247-855-11 CARBON 10K 5% 1/4W
R615 1-247-855-11 CARBON 10K 5% 1/4W
FRONT
