Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
51
C748 1-161-494-00 CERAMIC 0.022uF 25V
C749 1-161-494-00 CERAMIC 0.022uF 25V
C750 1-161-494-00 CERAMIC 0.022uF 25V
C751 1-126-943-11 ELECT 2200uF 20% 25V
C752 1-126-933-11 ELECT 100uF 20% 16V
C753 1-161-494-00 CERAMIC 0.022uF 25V
C754 1-161-494-00 CERAMIC 0.022uF 25V
C755 1-161-494-00 CERAMIC 0.022uF 25V
C756 1-126-934-11 ELECT 220uF 20% 16V
C757 1-126-934-11 ELECT 220uF 20% 16V
C758 1-161-494-00 CERAMIC 0.022uF 25V
C759 1-109-952-11 ELECT 0.47uF 20% 50V
C762 1-126-959-11 ELECT 0.47uF 20% 50V
C763 1-126-933-11 ELECT 100uF 20% 16V
C764 1-104-664-11 ELECT 47uF 20% 16V
< CONNECTOR >
* CN701 1-564-715-11 PIN, CONNECTOR (SMALL TYPE)13P
CN702 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
* CN703 1-564-510-11 PLUG, CONNECTOR 7P
< DIODE >
D701 8-719-027-23 DIODE GBU6D
D702 8-719-010-73 DIODE UZ-12BSA
D703 8-719-011-06 DIODE UZ-27BSA
D704 8-719-010-61 DIODE UZ-9.1BSA
D705 8-719-031-85 DIODE 1N4002L
D706 8-719-031-85 DIODE 1N4002L
D707 8-719-031-85 DIODE 1N4002L
D708 8-719-031-85 DIODE 1N4002L
D709 8-719-031-85 DIODE 1N4002L
D710 8-719-911-19 DIODE 1SS133
D712 8-719-911-19 DIODE 1SS133
D713 8-719-911-19 DIODE 1SS133
D714 8-719-911-19 DIODE 1SS133
D715 8-719-911-19 DIODE 1SS133
D716 8-719-911-19 DIODE 1SS133
D717 8-719-911-19 DIODE 1SS133
D718 8-719-911-19 DIODE 1SS133
D719 8-719-911-19 DIODE 1SS133
< FUSE >
! F701 1-532-388-31 FUSE 2A 250V (EXCEPT MX)
! F701 1-576-104-11 FUSE 2A 250V (MX)
< IC >
IC701 8-749-015-46 IC STK407-100E (DR3/DR330)
IC701 8-749-015-45 IC STK407-090E (XB200)
IC702 8-759-111-68 IC uPC1237HA
< TERMINAL >
JK703 1-694-443-11 TERMINAL BOARD (SPEAKER)
< COIL >
L702 1-420-872-00 COIL, AIR CORE (XB200)
L703 1-420-872-00 COIL, AIR CORE (XB200)
< TRANSISTOR >
Q702 8-729-188-23 TRANSISTOR 2SD882-P
Q703 8-729-200-36 TRANSISTOR 2SA966-Y
Q704 8-729-048-99 TRANSISTOR 2SK2541
Q705 8-729-048-99 TRANSISTOR 2SK2541
Q706 8-729-231-55 TRANSISTOR 2SC2878-A
Q707 8-729-231-55 TRANSISTOR 2SC2878-A
Q708 8-729-108-19 TRANSISTOR 2SA988TP-EA
Q709 8-729-231-55 TRANSISTOR 2SC2878-A
Q710 8-729-231-55 TRANSISTOR 2SC2878-A
Q711 8-729-184-53 TRANSISTOR 2SC1841TP-EA
Q712 8-729-184-53 TRANSISTOR 2SC1841TP-EA
Q713 8-729-026-29 TRANSISTOR 2SJ346
< RESISTOR >
R701 1-249-438-11 CARBON 56K 5% 1/4W
R702 1-249-438-11 CARBON 56K 5% 1/4W
R703 1-247-839-11 CARBON 2.2K 5% 1/4W
R704 1-247-839-11 CARBON 2.2K 5% 1/4W
R705 1-249-438-11 CARBON 56K 5% 1/4W
R706 1-249-438-11 CARBON 56K 5% 1/4W
R707 1-247-839-11 CARBON 2.2K 5% 1/4W
R708 1-247-839-11 CARBON 2.2K 5% 1/4W
R709 1-249-438-11 CARBON 56K 5% 1/4W
R710 1-249-438-11 CARBON 56K 5% 1/4W
R711 1-249-405-11 CARBON 100 5% 1/4W F
R712 1-249-417-11 CARBON 1K 5% 1/4W F
R713 1-249-417-11 CARBON 1K 5% 1/4W F
R714 1-249-405-11 CARBON 100 5% 1/4W F
R715 1-249-431-11 CARBON 15K 5% 1/4W
R716 1-249-431-11 CARBON 15K 5% 1/4W
R719 1-220-890-11 METAL 0.22 10% 3W
R720 1-220-890-11 METAL 0.22 10% 3W
R721 1-247-879-11 CARBON 100K 5% 1/4W
R722 1-247-879-11 CARBON 100K 5% 1/4W
R723 1-215-429-00 METAL 2.2K 1% 1/4W
R724 1-215-429-00 METAL 2.2K 1% 1/4W
R725 1-247-843-11 CARBON 3.3K 5% 1/4W
R726 1-247-843-11 CARBON 3.3K 5% 1/4W
R727 1-249-430-11 CARBON 12K 5% 1/4W
R728 1-249-430-11 CARBON 12K 5% 1/4W
R729 1-247-839-11 CARBON 2.2K 5% 1/4W
R730 1-247-871-11 CARBON 47K 5% 1/4W
R731 1-247-887-00 CARBON 220K 5% 1/4W
R732 1-249-417-11 CARBON 1K 5% 1/4W F
R733 1-249-438-11 CARBON 56K 5% 1/4W
R734 1-247-847-11 CARBON 4.7K 5% 1/4W
R735 1-249-455-11 CARBON 4.7 5% 1/4W
R736 1-249-455-11 CARBON 4.7 5% 1/4W
R737 1-247-784-00 CARBON 11 5% 1/4W
(XB200)
POWER (AMP)
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
To Next Page
