Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
52
R738 1-247-784-00 CARBON 11 5% 1/4W
(XB200)
R739 1-215-857-11 METAL OXIDE 10 5% 1W F
R740 1-216-450-00 METAL OXIDE 82 5% 2W F
(DR3/DR330)
R740 1-214-828-00 METAL 33 1% 1/2W
(XB200)
R742 1-249-413-11 CARBON 470 5% 1/4W F
R743 1-249-418-11 CARBON 1.2K 5% 1/4W F
R744 1-249-411-11 CARBON 330 5% 1/4W
R747 1-247-847-11 CARBON 4.7K 5% 1/4W
R748 1-247-855-11 CARBON 10K 5% 1/4W
R749 1-247-841-11 CARBON 2.7K 5% 1/4W
R750 1-247-839-11 CARBON 2.2K 5% 1/4W
R751 1-247-862-11 CARBON 20K 5% 1/4W
R752 1-247-855-11 CARBON 10K 5% 1/4W
R753 1-247-855-11 CARBON 10K 5% 1/4W
R754 1-247-895-00 CARBON 470K 5% 1/4W
R760 1-247-863-11 CARBON 22K 5% 1/4W
R761 1-247-855-11 CARBON 10K 5% 1/4W
R762 1-247-903-00 CARBON 1M 5% 1/4W
R763 1-247-879-11 CARBON 100K 5% 1/4W
R764 1-249-417-11 CARBON 1K 5% 1/4W F
R765 1-247-863-11 CARBON 22K 5% 1/4W
R766 1-247-863-11 CARBON 22K 5% 1/4W
< RELAY >
RL701 1-515-921-11 RELAY (12V)
************************************************************
1-674-633-11 REM BOARD
**********
< CAPACITOR >
C666 1-126-966-11 ELECT 33uF 20% 16V
< SENSOR >
RM601 8-749-013-84 IC SPS-447-1 (REMOTE SENSOR)
************************************************************
1-675-425-11 PHOTO SOCKET BOARD
*******************
< CAPACITOR >
C76 1-164-159-11 CERAMIC 0.1uF 50V
C76A 1-164-159-11 CERAMIC 0.1uF 50V
< PHOTOINTERRUPTER >
PH01 8-749-923-04 ICTOTX178A
< RESISTOR >
R76 1-249-417-11 CARBON 1K 5% 1/4W F
************************************************************
1-674-642-11 TR BOARD
********
< TRANSISTOR >
Q701 8-729-822-89 TRANSISTOR 2SD1667
************************************************************
1-674-631-11 VR BOARD
*********
< VARIABLE RESISTOR >
VR601 1-475-841-11 ENCODER (VOLUME)
************************************************************
MISCELLANEOUS
**************
124 1-772-164-11 DECK, MECH
135 1-783-579-11 WIRE (FLAT TYPE) (16 CORE)
! 151 1-551-506-99 CORD, POWER(DR3:E,MX,DR330)
! 151 1-555-795-00 CORD, POWER(DR3:SP/XB200:AEP,EE,CIS)
! 151 1-696-572-21 CORD, POWER(XB200:UK)
! 151 1-696-966-11 CORD, POWER(DR3:AU)
! 151 1-783-941-51 CORD, POWER(DR3:AR)
! 254 8-820-054-03 OPTICAL PICK UP KSM-213ECM/C2NP
256 1-769-856-11 WIRE(FLAT TYPE) (5 CORE)
M01 1-541-632-11 MOTOR DC
M101 X-2625-877-1 MOTOR ASSY (SPINDLE)
M102 X-2625-769-1 MOTOR ASSY (SLED)
! T001 1-433-921-11 TRANSFORMER, POWER(DR3:MX,DR330)
! T001 1-433-922-11 TRANSFORMER, POWER(XB200)
! T001 1-433-923-11 TRANSFORMER, POWER(DR3:E,SP,AR)
! T001 1-433-924-11 TRANSFORMER, POWER(DR3:AU)
*************
HARDWARELIST
*************
#1 7-685-903-21 SCREW +PTPWH 3 × 8 (TYPE2)
#2 7-685-871-09 SCREW +BVTT 3 × 6 (S)
#3 7-682-549-09 SCREW +B 3 × 10
#4 7-685-871-01 SCREW +BVTT 3 × 6 (S)
#5 7-685-863-09 SCREW +BVTT 2.6 × 8 (S)
#6 7-685-646-79 SCREW +BVTP 3 × 8 TYPE2 TT(B)
#7 7-685-647-79 SCREW, TAPPING
#9 7-682-904-11 SCREW +PWH 4 × 8
#10 7-681-000-61 SCREW +PWH M3 × 8
#11 7-685-902-11 SCREW +PWH 2.6 × 6
#14 7-621-255-15 SCREW +P 2 × 3
REM TR VRPOWER (AMP)
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
HCD-DR3/DR330/XB200
Sony Corporation
Home Audio Company
9-928-976-11
99F1671-1
Printed in Japan ©1999.6
Published by Quality Assurance Dept.
PHOTO SOCKET
