7-12. PRINTED WIRING BOARD — AMP, POWER (EXCEPT AEP, UK, RU, KR, AUS MODELS) SECTION —
• See page 21 for Circuit Boards Location.
:Uses unleaded solder.
• Semiconductor
Location
Ref. No. Location
D101 C-3
D102 C-4
D103 C-4
D104 C-4
D311 D-3
D351 C-6
IC103 D-4
Q101 C-10
Q102 C-10
Q103 C-9
Q104 C-9
Q105 C-10
Q301 C-9
Q303 C-9
Q304 B-10
Q308 C-10
Q309 D-11
Q310 D-11
Q311 E-3
Q312 D-2
Q314 C-11
• Semiconductor
Location
Ref. No. Location
D901 G-2
D902 H-2
D903 G-2
D904 G-2
D905 F-3
D906 G-2
D907 H-2
• Semiconductor
Location
Ref. No. Location
D901 G-8
D902 H-8
D903 G-8
D904 G-8
D905 F-8
D906 G-8
D907 H-8
(US, CND MODEL )
(E2, E3, E51, SP, TW MODEL)
IC103
1
2
1
2
AMP BOARD AMP BOARD
12
A
B
C
D
E
F
G
H
I
J
3456789101112
MAIN
BOARD
CN107
(Page 26)
MAIN
BOARD
CN103
(Page 26)
H
I
MAIN
BOARD
CN105
(Page 26)
E
HP
BOARD
CW101
(Page 32)
K
E
E
MAIN
BOARD
CN301
(Page 26)
D
FAN
AC IN
* Not replaceable : Built in transformer
(US,CND MODELS)(E2, E3, E51, SP, TW MODELS)
POWER BOARDPOWER BOARD
MAIN
BOARD
CN301
(Page 26)
D
PT901
AC IN
* Not replaceable
: Built in transformer
*
POWER TRANSFORMER(MAIN)
POWER TRANSFORMER(SUB)
E
1
510
15
SW901
110 - 120V
220 - 240V
VOLTAGE
SELECTOR
E2,E3,E51,SP
TW
TW
POWER TRANSFORMER(SUB)
*
1
11
1
11
4
1
9
5
4
1
9
5
