HCD-DV2D
SECTION 9
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . , uPA. . , µPA. . ,
uPB. . : µPB. . , uPC. . , µPC. . ,
uPD. . : µPD. .
•Abbreviation
AUS:Australian model
CND : Canadian model.
E2 : 120 V AC area in E model.
E3 : 240 V AC area in E model.
E51 : Chilean and Peruvian model.
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
KR : Korea model.
RU : Russian model.
SP : Singapore model.
TW : Taiwan model.
9-885-080-00 AMP BOARD, COMPLETE
********************
< CAPACITOR >
C159 1-126-963-91 CAP, ELECT 4.7MF
C160 1-126-963-91 CAP, ELECT 4.7MF
C163 1-164-315-91 CAP, CERAMIC 470PF CH 1608
C164 1-164-315-91 CAP, CERAMIC 470PF CH 1608
C165 1-126-968-91 CAP, ELECT 100MF
C166 1-126-968-91 CAP, ELECT 100MF
C167 1-162-908-91 CAP, CERAMIC 3P
C168 1-162-908-91 CAP, CERAMIC 3P
C176 1-126-971-51 CAP, ELECT 470/50V
C177 1-104-661-91 CAP, ELECT 330MF
C178 1-126-968-91 CAP, ELECT 100MF
C179 1-131-992-91 CAP, CERAMIC 100000PF F 1608
C180 1-126-968-91 CAP, ELECT 100MF
C181 1-131-992-91 CAP, CERAMIC 100000PF F 1608
C182 1-126-971-91 CAP, ELECT 220MF
C183 1-126-971-91 CAP, ELECT 220MF
C308 1-162-970-91 CAP, CERAMIC 10000PF B 1608
C311 1-126-933-91 CAP, ELECT 100MF
C327 1-126-963-91 CAP, ELECT 4.7MF
C328 1-126-941-91 CAP, ELECT 470MF
C329 1-131-992-91 CAP, CERAMIC 100000PF F 1608
C330 1-126-767-91 CAP, ELECT 1000MF
C334 1-126-961-91 CAP, ELECT 2.2MF
< CONNECTOR >
CN101 1-564-508-11 PLUG, CONNECTOR 5P
CN102 1-564-510-11 PLUG, CONNECTOR 7P
CN106 1-564-506-11 PLUG, CONNECTOR 3P
CN350 1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D101 8-719-991-33 DIODE 1SS133T-77
D102 8-719-991-33 DIODE 1SS133T-77
D103 8-719-991-33 DIODE 1SS133T-77
D104 8-719-991-33 DIODE 1SS133T-77
D311 8-719-923-84 DIODE MTZJ-T-77-13B
D351 8-719-991-33 DIODE 1SS133T-77 (US,CND)
< IC >
IC103 6-705-621-01 IC STK433-070
< TRANSISTOR >
Q101 8-729-200-71 TRANSISTOR 2SC2712G-TE85L
Q102 8-729-200-71 TRANSISTOR 2SC2712G-TE85L
Q103 8-729-200-75 TRANSISTOR 2SA1162G-TE85L
Q104 8-729-200-75 TRANSISTOR 2SA1162G-TE85L
Q105 8-729-028-83 TRANSISTOR DTA124EUA-T106
Q301 8-729-200-71 TRANSISTOR 2SC2712G-TE85L
Q303 8-729-200-71 TRANSISTOR 2SC2712G-TE85L
Q304 8-729-200-71 TRANSISTOR 2SC2712G-TE85L
Q308 8-729-027-46 TRANSISTOR DTC114YKA-T146
Q309 8-729-028-83 TRANSISTOR DTA124EUA-T106
Q310 8-729-027-46 TRANSISTOR DTC114YKA-T146
Q311 8-729-924-92 TRANSISTOR 2SB1370-E
Q312 6-550-333-01 TRANSISTOR 2SC5343GL
Q314 8-729-200-75 TRANSISTOR 2SA1162G-TE85L
< RESISTOR >
R151 1-247-847-91 RES, CHIP (SMALL) 4.7K
R163 1-216-827-91 RES, CHIP 3.3K (1608)
R164 1-216-827-91 RES, CHIP 3.3K (1608)
R165 1-216-822-91 RES, CHIP 1.2K (1608)
R166 1-216-822-91 RES, CHIP 1.2K (1608)
R167 1-216-842-91 RES, CHIP 56K (1608)
R168 1-216-842-91 RES, CHIP 56K (1608)
R169 1-216-819-91 RES, CHIP 680 (1608)
R170 1-216-819-91 RES, CHIP 680 (1608)
R171 1-216-361-81 RES, METAL OXIDE FILM 0.22
R172 1-216-361-81 RES, METAL OXIDE FILM 0.22
R173 1-216-361-81 RES, METAL OXIDE FILM 0.22
R174 1-216-361-81 RES, METAL OXIDE FILM 0.22
R175 1-216-842-91 RES, CHIP 56K (1608)
R176 1-216-842-91 RES, CHIP 56K (1608)
R177 1-216-821-91 RES, CHIP 1K (1608)
R178 1-216-821-91 RES, CHIP 1K (1608)
R179 1-216-835-91 RES, CHIP 15K (1608)
R180 1-216-835-91 RES, CHIP 15K (1608)
R185 1-216-845-91 RES, 100K (1608)
R186 1-216-845-91 RES, 100K (1608)
R190 1-212-881-91 RES, FUSE 100
R191 1-212-881-91 RES, FUSE 100
R301 1-216-845-91 RES, 100K (1608)
R302 1-216-845-91 RES, 100K (1608)
R303 1-216-833-91 RES, CHIP 10K (1608)
R307 1-216-845-91 RES, 100K (1608)
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
AMP
Ver. 1.2
