Sony HCD-DV2D - Page 59

59
HCD-DV2D
Ref. No. Part No. Description Remark
R316 1-259-033-91 RES, CARBON (SMALL) 1
R317 1-259-033-91 RES, CARBON (SMALL) 1
R318 1-259-033-91 RES, CARBON (SMALL) 1
R319 1-247-831-91 RES, CARBON (SMALL) 1
R329 1-216-845-91 RES, 100K (1608)
R358 1-216-833-91 RES, CHIP 10K (1608)
R359 1-216-821-91 RES, CHIP 1K (1608)
R360 1-216-837-91 RES, CHIP 22K (1608)
************************************************************
9-885-077-13 AV BOARD, COMPLETE (EXCEPT AEP,UK,RU)
9-885-079-98 AV BOARD, COMPLETE (AEP,UK,RU)
*******************
< CAPACITOR >
C851A 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
(EXCEPT AEP,UK,RU)
C851B 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608 (AEP,UK,RU)
C891 1-162-968-91 CAP, CHIP CERAMIC 0.01MF F 1608
(AEP,UK,RU)
< CONNECTOR >
CN851A 1-784-766-11 CONNECTOR,5P (EXCEPT AEP,UK,RU)
CN851B 1-784-772-11 CONNECTOR,11P (AEP,UK,RU)
< FERRITE BEAD >
FB851A 9-885-060-35 BEAD, FERRITE (EXCEPT AEP,UK,RU)
FB851B 9-885-060-35 BEAD, FERRITE (AEP,UK,RU)
FB852 9-885-060-35 BEAD, FERRITE (AEP,UK,RU)
FB853 9-885-060-35 BEAD, FERRITE (AEP,UK,RU)
FB854 9-885-060-35 BEAD, FERRITE (AEP,UK,RU)
< JACK >
JK801A 9-885-059-83 OPTICAL TRANSMITTER PLT13
(DIGITAL OUT OPTICAL) (EXCEPT AEP,UK,RU)
JK801B 9-885-059-83 OPTICAL TRANSMITTER PLT13
(DIGITAL OUT OPTICAL) (AEP,UK,RU)
JK802 9-885-059-85 JACK, PIN 1P (VIDEO OUT)
(EXCEPT AEP,UK,RU)
< CONNECTOR >
JK803B 9-885-061-75 CONNECTOR(21P) (t LINE-TV) (AEP,UK,RU)
< COIL >
L851A 1-410-328-11 INDUCTOR, MICRO 10UH (EXCEPT AEP,UK,RU)
L851B 1-410-328-11 INDUCTOR, MICRO 10UH (AEP,UK,RU)
< RESISTOR >
R851 1-216-821-91 RES, 1K (1608) (EXCEPT AEP,UK,RU)
R858 1-216-821-91 RES, 1K (1608) (AEP,UK,RU)
************************************************************
9-885-077-08 KEY BOARD, COMPLETE
(including HP BOARD)
**********************
< CAPACITOR >
C161 1-162-970-91 CAP, CERAMIC 10000PF B 1608
C162 1-162-970-91 CAP, CERAMIC 10000PF B 1608
C166 9-885-068-70 CAP, CHIP CERAMIC 0.1MF 50V
C651 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C652 1-124-240-61 CAP, ELECT 10MF
C655 1-162-970-91 CAP, CERAMIC 10000PF B 1608
C656 1-162-970-91 CAP, CERAMIC 10000PF B 1608
C657 1-162-970-91 CAP, CERAMIC 10000PF B 1608
C659 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C660 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C661 1-126-967-91 CAP, ELECT 47MF
C662 1-126-967-91 CAP, ELECT 47MF
C663 1-162-968-91 CAP,CHIP CERAMIC 4700PF B 1608
C664 1-162-968-91 CAP,CHIP CERAMIC 4700PF B 1608
C665 1-162-970-91 CAP, CERAMIC 10000PF B 1608
C666 1-124-584-61 CAP, ELECT 100MF
C670 1-162-960-91 CAP,CHIP CERAMIC 220PF B 1608
< CONNECTOR >
CN601 1-784-782-11 CONNECTOR, FFC 21P
CN602 1-784-729-11 CONNECTOR, FFC 7P
< DIODE >
D651 8-719-991-33 DIODE 1SS133T-77
D652 8-719-045-62 DIODE SLR-342VCT31 ( ?/1)
D654 8-719-991-33 DIODE 1SS133T-77
< IC >
IC651 8-759-643-83 IC UPD16315GB-3BS
IR651 6-701-681-01 IC RPM7140-V4 ( )
< JACK >
JK103 9-885-059-95 JACK, HEADPHONE (PHONES)
< SHORT >
JR120 1-216-864-91 CONDUCTOR, CHIP (1608)
JR651 1-216-864-91 CONDUCTOR, CHIP (1608)
JR652 1-216-864-91 CONDUCTOR, CHIP (1608)
JR802 1-216-864-21 C-JUMPER
< COIL >
L105 1-414-140-11 INDUCTOR, MICRO 0.68UH
< TRANSISTOR >
Q651 6-550-297-01 TRANSISTOR 2SA1981Y
Q652 8-729-200-71 TRANSISTOR 2SC2712G-TE85L
Q653 6-550-305-01 TRANSISTOR 2SA1296GR-(TPE2)
Q654 8-729-900-58 TRANSISTOR DTC114EK-T146
< RESISTOR >
R153 1-247-817-91 RES, CARBON (SMALL) 270
R154 1-247-817-91 RES, CARBON (SMALL) 270
R155 1-247-815-91 RES, CARBON (SMALL) 220
R156 1-247-815-91 RES, CARBON (SMALL) 220
R651 1-216-808-91 RES, 82 (1608)
AV
AMP
Ver 1.2
KEY
