Sony HCD-DV2D - MPEG Section Parts List

65
HCD-DV2D
Ref. No. Part No. Description Remark
R531 1-247-855-91 RES, CARBON (SMALL) 10K
R533 1-216-833-91 RES, CHIP 10K (1608)
R534 1-216-809-91 RES, CHIP 100 (1608)
R535 1-216-833-91 RES, CHIP 10K (1608)
R536 1-216-803-91 RES, CHIP 33 (1608)
R537 1-216-829-91 RES, CHIP 4.7K (1608)
R538 1-216-821-91 RES, CHIP 1K (1608)
R539 1-216-817-91 RES, CHIP 470 (1608)
R540 1-216-821-91 RES, CHIP 1K (1608)
R541 1-216-821-91 RES, CHIP 1K (1608)
R542 1-216-821-91 RES, CHIP 1K (1608)
R543 1-247-879-91 RES, CARBON (SMALL) 100K
R547 1-216-833-91 RES, CHIP 10K (1608)
R548 1-216-833-91 RES, CHIP 10K (1608)
R549 1-216-821-91 RES, CHIP 1K (1608)
R550 1-216-821-91 RES, CHIP 1K (1608)
R552 1-216-821-91 RES, CHIP 1K (1608)
R553 1-216-821-91 RES, CHIP 1K (1608)
R554 1-216-821-91 RES, CHIP 1K (1608)
R556 1-216-833-91 RES, CHIP 10K (1608)
R557 1-216-821-91 RES, CHIP 1K (1608)
R558 1-216-833-91 RES, CHIP 10K (1608)
R559 1-216-821-91 RES, CHIP 1K (1608)
R560 1-216-821-91 RES, CHIP 1K (1608)
R561 1-216-821-91 RES, CHIP 1K (1608)
R562 1-216-849-91 RES, CHIP 220K (1608)
R563 1-216-844-91 RES, CHIP 82K (1608)
R565 1-216-842-91 RES, CHIP 56K (1608)
R566 1-216-841-91 RES, CHIP 47K (1608)
R567 1-216-825-91 RES, CHIP 2.2K (1608)
R568 1-216-821-91 RES, CHIP 1K (1608)
R569 1-216-825-91 RES, CHIP 2.2K (1608)
R570 1-216-819-91 RES, CHIP 680 (1608)
R571 1-216-821-91 RES, CHIP 1K (1608)
R572 1-216-833-91 RES, CHIP 10K (1608)
R573 1-216-841-91 RES, CHIP 47K (1608)
R574 1-247-855-91 RES, CARBON (SMALL) 10K
R576 1-216-819-91 RES, CHIP 680 (1608)
R577 1-216-821-91 RES, CHIP 1K (1608)
R578 1-216-829-91 RES, CHIP 4.7K (1608)
R581 1-216-822-91 RES, CHIP 1.2K (1608) (AEP,UK)
R581 1-216-826-91 RES, CHIP 2.7K (1608) (SP,KR,TW)
R581 1-216-829-91 RES, CHIP 4.7K (1608) (US,CND,E2,E51)
R581 1-216-833-91 RES, CHIP 10K (1608) (RU)
R581 1-218-292-91 RES, CHIP24K (1608) (AUS,E3)
R582 1-216-864-91 CONDUCTOR, CHIP (1608)
R583 1-216-838-91 RES, CHIP 27K (1608)
R584 1-247-855-91 RES, CARBON (SMALL) 10K
(EXCEPT US,CND,SP,E2,E3)
R584 1-216-833-91 RES, CHIP 10K (1608) (US,CND,SP,E2,E3)
R585 1-247-855-91 RES, CARBON (SMALL) 10K
(EXCEPT US,CND,SP,E2,E3)
R585 1-216-833-91 RES, CHIP 10K (1608) (US,CND,SP,E2,E3)
R586 1-216-864-91 CONDUCTOR, CHIP (1608)
< TRANSFORMER >
T201 9-885-059-58 OSCILLATION, BIAS TRANSFORMER
< VIBRATOR >
X501 9-885-059-48 VIBRATOR, CRYSTAL (32.768KHz)
X502 9-885-059-52 OSCILLATOR, CERAMIC (8.38MHz)
************************************************************
9-885-077-15 MPEG BOARD, COMPLETE (US,CND)
9-885-079-69 MPEG BOARD, COMPLETE (SP,KR,TW)
9-885-079-70 MPEG BOARD, COMPLETE (AEP,UK)
9-885-079-71 MPEG BOARD, COMPLETE (AUS)
9-885-079-72 MPEG BOARD, COMPLETE (E2,E51)
9-885-079-73 MPEG BOARD, COMPLETE (E3)
9-885-079-99 MPEG BOARD, COMPLETE (RU)
*********************
< CAPACITOR >
C128 1-162-968-91 CAP,CHIP CERAMIC 4700PF B 1608
C701 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C702 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C703 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C704 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C705 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C706 1-115-340-91 CAP, CERAMIC 24PF CH 1608 (AEP,UK,RU)
C707 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C712 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C713 1-126-925-71 CAP, ELECT 470MF
C714 1-104-664-71 CAP, ELECT 47MF
C715 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C716 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C717 1-126-925-71 CAP, ELECT 470MF
C718 1-126-933-71 CAP, ELECT 100MF
C719 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C720 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C723 1-126-933-71 CAP, ELECT 100MF
C724 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C727 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C728 1-126-964-71 CAP, ELECT 10MF
C729 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C734 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C735 1-104-664-71 CAP, ELECT 47MF
C736 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C737 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C738 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C739 1-115-416-91 CAP,CHIP CERAMIC1000PF CH 1608
C742 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C747 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C748 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C751 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C752 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C753 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C754 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C755 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C756 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C760 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C763 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C764 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C765 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C766 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
C767 1-164-156-91 CAP, CHIP CERAMIC 0.1MF F 1608
MAIN MPEG
Ver. 1.2
